01 MARUMO

Complete noise reduction LNC2-400-1500W / LNC2-400-2000W
When spotlights are turned on and off, heat from Model LNC2-400-1500W LNC2-400-2000W
the lamp causes the metal elements of the light Voltage AC 100 V
body to expand and contract, producing distortion Wattage 1500W
which contributes to the noise. MARUMO has Suitable Lamp JP100V1500W/G-D JP100V2000W/G-D
reduced noise occurrence to a minimum by JP100V1500WB/G JP100V2000WB/G-2
incorporating materials, design, and construction JP100V1500WC/G JP100V2000WC/G-2
to control this distortion as much as possible. Maximum Ambient Temperature 40°C
Maximum Surface Temperature 180°C 205°C
Body Weight 16.2kg
Tilt Angle/Suspended Use UP60 DN60°
Tilt Angle/Stand Use UP50 DN50°
Minimum Safe Interval to Flammable Object 0.4m 0.5m
Minimum Throw Distance 4.1m/※2.0m 4.4m/※2.0m
from Flammable ObjectInput (φ0.3m) (φ0.3m)
ASPHERICAL PLANO- ASPHERICAL PLANO-
Lens CONVEX 253D355F CONVEX 253D355F
Lamp Base G16 G22
Cable Length 1.5m
Plug C-30P
Body Material Aluminum
Color Black
Color Frame 295mm×295mm
SPOTLIGHT & FLOODLIGHT
※When used below the minimum established throw distance (up to 2 meters) , please

SPH use a projection diameter larger than the indicated values.

A highly concentrated and bright lighting can be produced without using a lens.
Furnishing a sealed beam halogen bulb, this spotlight series provides a bright and effective beam with no lens.

1 2 Compact Square Shaped SPH
The SPHIII model is available in both 500 watts and 1000 watts
SPH-500W is a compact 500W model.
This sturdy lamp body provides good lighting in a wide variety of
applications. Available in black aluminum, or polished aluminum finish.

SPHIII-500W-AL / SPHIII-1000W-AL SPHIII-500W-ALP / SPHIII-1000W-ALP
Model SPHIII-500W-AL SPHIII-1000W-AL Model SPHIII-500W-AL SPHIII-1000W-AL
Voltage AC 100 V Voltage AC 100 V
Wattage 500W Wattage 500W
Suitable Lamp JP100V500WC/VN/S6/E JP100V1000WC/VN/S6/E Suitable Lamp JP100V500WC/VN/S6/E JP100V1000WC/VN/S6/E
JP100V500WC/N/S6/E JP100V1000WC/N/S6/E JP100V500WC/N/S6/E JP100V1000WC/N/S6/E
JP100V500WC/M/S6/E JP100V1000WC/M/S6/E JP100V500WC/M/S6/E JP100V1000WC/M/S6/E
JP100V500WCSB6VN/E JP100V1000WCSB6N/E JP100V500WCSB6VN/E JP100V1000WCSB6N/E
JP100V500WCSB6N/E JP100V1000WCSB6M/E JP100V500WCSB6N/E JP100V1000WCSB6M/E
JP100V500WCSB6M/E JP100V500WCSB6M/E
Maximum Ambient Temperature 40°C Maximum Ambient Temperature 40°C
Maximum Surface Temperature 115°C 170°C Maximum Surface Temperature 145°C 225°C
Body Weight 3.4kg Body Weight 3.4kg
Tilt Angle/Suspended Use UP60° DN90° Tilt Angle/Suspended Use UP60° DN90°
Tilt Angle/Stand Use UP90° DN60° Tilt Angle/Stand Use UP90° DN60°
Minimum Safe Interval to Flammable Object 0.2m 0.3m Minimum Safe Interval to Flammable Object 0.2m 0.3m
Minimum Throw Distance Minimum Throw Distance
from Flammable ObjectInput 2.9m※ 2.4m※ from Flammable ObjectInput 2.9m※ 2.6m※
Lamp Base EMEP Lamp Base EMEP

34
