ECR2-ZM2035-750 Zoom 20°~35°
Voltage 100V Lamp Base G9.5
Suitable Lamp Wattage 500W 575W 650W 750W Cable Length 1.2m
Maximum Ambient Temperature 40°C Yoke※ Balance Arm
Maximum Surface Temperature 220°C Plug C-20P
Body Weight 12.2kg Body MaterialAluminum Magnesium
Tilt Angle/Suspended Use UP65° DN90° Color Black
Tilt Angle/Stand Use UP90° DN70° Color Frame 191mm×191mm
Minimum Safe Interval to Flammable Object 0.5m

Minimum Safe Interval to Flammable Object 1.0m
ECR2-ZW3050-750 Zoom 30°~50°
Voltage 100V Lamp Base G9.5
Suitable Lamp Wattage 500W 575W 650W 750W Cable Length 1.2m
Maximum Ambient Temperature 40°C Yoke※ Normal Arm Aluminum
Maximum Surface Temperature 220°C Plug C-20P
Body Weight 9.0kg Body MaterialAluminum Magnesium
Tilt Angle/Suspended Use UP70° DN90° Color Black
Tilt Angle/Stand Use UP90° DN65° Color Frame 191mm×191mm
Minimum Safe Interval to Flammable Object 0.5m

Minimum Safe Interval to Flammable Object 0.8m

Ivory color model
[Custom made]

⁕ LensTube

There are seven kinds of lens tube variation of RIKURI 2. And the change can be accomplished easily loosening just one bolt.

LTE2-19C LTE2-26C LTE2-36C LTE2-50C

LTE2-ZN1525 LTE2-ZM2035 LTE2-ZW3050

Model LTE2-19C LTE2-26C LTE2-36C LTE2-50C LTE2-ZN1525 LTE2-ZM2035 LTE2-ZW3050
Maximum Surface Temperature 40° 40° 40° 40° 40° 40° 40°
Body Weight 1.9kg 1.8kg 1.7kg 1.5kg 5.6kg 4.5kg 3.4kg
Field Beam Angle 19° 26° 36° 50° 15°~25° 20°~35° 30°~50°
Body Material Magnesium Magnesium Magnesium Magnesium Magnesium Magnesium Magnesium
Color Black Black Black Black Black Black Black
Color Frame 158mm×158mm 158mm×158mm 158mm×158mm 158mm×158mm 191mm×191mm 191mm×191mm 191mm×191mm

⁕ ColorExtender
An adapter that fits in the RIKURI 2 filter holder and greatly reduces filter burn. Three variations are available for matching
lamp houses.
