FQH2-106S2-2000
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.6m
Wattage 2000W Minimum Throw Distance from Flammable Object 2.0m
Suitable Lamp JP100V2000WB/G-2 Lens MENISCUS HIVEX 250D150F S2
JP100V2000WC/G-2 Lamp Base G22
Maximum Ambient Temperature 40°C Cable Length1.5m
Maximum Surface Temperature 295°C Plug C-30P
Body Weight 7.8kg Body Material Aluminum
Tilt Angle/Suspended Use UP45° DN90° Color Black
Tilt Angle/Stand Use UP90° DN45° Color Frame 295mm×295mm

SPOTLIGHT & FLOODLIGHT
FQH

The FQH creates soft focus lighting by using the latest lens technology.
The HIVEX lens has received high praise for its light weight and beautiful light quality. This spotlight was created using a
Meniscus type HIVEX lens developed from the latest advances in optical technology. Users can create soft, bright, and highly
efficient lighting on stage or in the studio.

FQH-3000WS1 / FQH-3000WS2
Model FQH-3000WS1 FQH-3000WS2 Minimum Safe Interval to Flammable Object 0.5m
Voltage AC 100 V Minimum Throw Distance 4.1m 2.4m
Wattage 3000W from Flammable ObjectInput
Suitable Lamp JP100V3000WB/G-2 JP100V3000WB/G-2 MENISCUS-HIVEX MENISCUS-HIVEX
JP100V3000WC/G-2 JP100V3000WC/G-2 Lens 300D180FS1 300D180FS2
Body Material 3.0kg Lamp Base G38
Maximum Ambient Temperature 40°C Cable Length 1.5m
Maximum Surface Temperature 190°C Plug C-30P
Body Weight/Barndoor Weight 10.0kg / 1.9kg Body Material Aluminum
Tilt Angle/Suspended Use UP30 DN90° Color Black
Tilt Angle/Stand Use UP90 DN40° Color Frame 355mm×355mm

FQH-5000WS1 / FQH-5000WS2
Model FQH-5000WS1 FQH-5000WS2
Voltage AC 100 V Minimum Throw Distance
Wattage 5000W from Flammable ObjectInput 4.3m 2.5m
Suitable Lamp JP100V5000WB/G-2 JP100V5000WB/G-2 MENISCUS-HIVEX MENISCUS-HIVEX
JP100V5000WC/G-2 JP100V5000WC/G-2 Lens 300D180FS1 300D180FS2
Maximum Ambient Temperature 40°C Lamp Base G38
Maximum Surface Temperature 250°C Cable Length 1.5m
Body Weight/Barndoor Weight 11.7kg / 1.9kg Plug C-60P
Tilt Angle/Suspended Use UP30 DN45° Body Material Aluminum
Tilt Angle/Stand Use UP45 DN40° Color Black
Minimum Safe Interval to Flammable Object 0.6m Color Frame 355mm×355mm

SPOTLIGHT & FLOODLIGHT
LN

The LN series brings silence to the theater.
Spotlights make a click or pop when they are turned on or off. When many spotlights are used together in a theater, these
clicks and pops become a noise problem. Through research and analysis, MARUMO Electric has identified the mechanism
that causes this noise and has steadily worked to resolve it. The LN spotlights use new materials and a new design for the
lamp body so that the quiet atmosphere in a concert hall will not be disrupted. LN spotlights have double slots for filter
frames. It secures frames better and enables to add another color.
