Cable Length 1.0m Cable Length 1.0m
Plug C-20P Plug C-20P
Body Material Aluminum Body Material Aluminum
Color Black Color Silver
Color Frame 245mm×245mm Color Frame 245mm×245mm
※The value when type VN light bulb was used 2.4m when N type ※The value when type VN light bulb was used 2.4m when N type

light bulb was used. light bulb was used.

SPH-500W
Voltage AC 100 V Tilt Angle/Stand Use UP90° DN55°
Wattage 500W Minimum Safe Interval to Flammable Object 0.2m
Suitable Lamp JP100V500WC/N/S3/S Minimum Throw Distance from Flammable Object 1.6m
JP100V500WC/W/S3/S Lamp Base M4 Screw base
JP100V500WCSB3N/S Cable Length1.0m
JP100V500WCSB3W/S Plug C-20P
Maximum Ambient Temperature 40°C Body Material Steel
Maximum Surface Temperature 150°C Color Black
Body Weight 2.6kg Color Frame 150mm×150mm
Tilt Angle/Suspended Use UP55° DN90°

Long-selling T1
SPOTLIGHT & FLOODLIGHT 1
Since its launch, it has become a best seller of planoconvex lenses that have
T1/DF/BNQ long been favorites of many users. Compact, lightweight and easily adjusted, this
has great lighting power in small spaces.

Legacy line-up that has long been 2 Floodlight BNQ
The BNQ is called a bunchlight, and is an independent floodlight having a
a favorite product.
500W halogen lamp. This gives a soft light and is used in small illumination.
T1, DF and BNQ are some of
MARUMO’s best sellers as evidenced 3 DF2 with brighter, more beautiful light
Our best-selling DF Fresnel lens spotlights now use Meniscus HIVEX lenses,
by their long being favorite products on to be newly registered as the DF2. They make possible brighter, more beautiful
stages and halls across the country. light. With a compact body for easy handling, this allows users to select its
location of setup, such as by suspension in narrow spaces.

T1-500W
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.2m
Wattage 500W Minimum Throw Distance from Flammable Object 1.0m
Suitable Lamp JP100V500WB/E Lens PLANO-CONVEX 114D178F
G100V500WB Lamp Base E26
GR100V500WB Cable Length1.0m
Maximum Ambient Temperature 40°C Plug C-20P
Maximum Surface Temperature 175°C Body Material Steel
Body Weight 5.9kg Color Black
Tilt Angle/Suspended Use UP45° DN90° Color Frame 150mm×150mm
Tilt Angle/Stand Use UP90° DN55°

DF2-500
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.2m
Wattage 500W Minimum Throw Distance from Flammable Object 1.6m
Suitable Lamp JP100V500WB/E Lens MENISCUS HIVEX150D95F
T100V500WB Lamp Base E26
Maximum Ambient Temperature 40°C Cable Length1.0m
Maximum Surface Temperature 150°C Plug C-20P
Body Weight 3.3kg Body Material Steel
Tilt Angle/Suspended Use UP25° DN90° Color Black
Tilt Angle/Stand Use UP90° DN55° Color Frame 195mm×195mm

35
