01 MARUMO

MSH-810-1500
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.6m
Wattage 1500W Minimum Throw Distance from Flammable Object 1.0m
Suitable Lamp JP100V1000W/HT Lens HIVEX 200D250F
JP100V1500W/HT Lamp Base G22
Maximum Surface Temperature 40°C Cable Length 2.0m
Maximum Surface Temperature 295°C Plug C-20P
Body Weight 7.4kg Body Material Aluminum
Tilt Angle/Suspended Use UP55° DN90° Color Black
Tilt Angle/Stand Use UP90° DN55° Color Frame 245mm×245mm

MSC-814-1500
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.6m
Wattage 1500W Minimum Throw Distance from Flammable Object 1.0m
Suitable Lamp JP100V1000W/HT Lens ASPHERICAL PLANO-CONVEX 200D356F
JP100V1500W/HT Lamp Base G22
Maximum Surface Temperature 40°C Cable Length 2.0m
Maximum Surface Temperature 295°C Plug C-20P
Body Weight 9.5kg Body Material Aluminum
Tilt Angle/Suspended Use UP55° DN90° Color Black
Tilt Angle/Stand Use UP90° DN55° Color Frame 245mm×245mm

MSH-814-1500
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.6m
Wattage 1500W Minimum Throw Distance from Flammable Object 1.5m
Suitable Lamp JP100V1000W/HT Lens HIVEX 200D350F
JP100V1500W/HT Lamp Base G22
Maximum Surface Temperature 40°C Cable Length 2.0m
Maximum Surface Temperature 295°C Plug C-20P
Body Weight 8.3kg Body Material Aluminum
Tilt Angle/Suspended Use UP55° DN90° Color Black
Tilt Angle/Stand Use UP90° DN55° Color Frame 245mm×245mm

MSM-604S1-750
Voltage AC 100 V Tilt Angle/Suspended Use UP40° DN90°
Wattage 750W Tilt Angle/Stand Use UP90° DN40°
Suitable Lamp JP100V500W/HT Minimum Safe Interval to Flammable Object 0.4m
JP100V500WC/G-2 Minimum Throw Distance from Flammable Object 1.5m
JP100V500WB/G-2 Lens MENISCUS HIVEX 150D95F S1
JP100V750W/HT Lamp Base GX9.5
JP100V750WC/G-2 Cable Length 1.0m
JP100V750WB/G-2 Plug C-20P
Maximum Surface Temperature 40°C Body Material Aluminum
Maximum Surface Temperature 245°C Color Black
Body Weight 3.9kg Color Frame 195mm×195mm

MSM-604S2-750
Voltage AC 100 V Tilt Angle/Suspended Use UP40° DN90°
Wattage 750W Tilt Angle/Stand Use UP90° DN40°
Suitable Lamp JP100V500W/HT Minimum Safe Interval to Flammable Object 0.4m
JP100V500WC/G-2 Minimum Throw Distance from Flammable Object 1.0m
JP100V500WB/G-2 Lens MENISCUS HIVEX 150D95F S2
JP100V750W/HT Lamp Base GX9.5
JP100V750WC/G-2 Cable Length 1.0m
JP100V750WB/G-2 Plug C-20P
Maximum Surface Temperature 40°C Body Material Aluminum
Maximum Surface Temperature 245°C Color Black
Body Weight 3.9kg Color Frame 195mm×195mm
