MSC-608-750
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.4m
Wattage 750W Minimum Throw Distance from Flammable Object 0.5m
Suitable Lamp JP100V500W/HT Lens ASPHERICAL PLANO-CONVEX 152D203F
JP100V750W/HT Lamp Base GX9.5
Maximum Surface Temperature 40°C Cable Length 1.0m
Maximum Surface Temperature 230°C Plug C-20P
Body Weight 5.1kg Body Material Aluminum
Tilt Angle/Suspended Use UP50° DN90° Color Black
Tilt Angle/Stand Use UP90° DN50° Color Frame 195mm×195mm

SPOTLIGHT & FLOODLIGHT
FQH2

A brand-new spotlight series specifically for television studios.
The FQH2 Series of television studio spotlights meet the particular
needs of these studios (which differ from the environment and
conditions of the stage) for brilliance, compactness, lightweight
design and portability.

Realizing a compact and lightweight design
1
Every effort has been made to create a compact and lightweight design to
meet the particularities of television studio lighting for fast preparatory work
and the incorporation of several pieces of equipment. In addition to
modifying the lamp body and its thermal insulation construction by adding a
vent at its rear, we have strengthened the body of the equipment through
careful selection of components, achieving a compact and lightweight
design. Also realizes low noise levels, minimizing cracks and pops.

Geometrical design raising ease of operation
3 and convenience
Operability is enhanced by use of a large geometrical handle
shape to operate the light, and the use of plastic for the
entire handle reduces heat conductivity from the lamp body,
making handling easier. The vents are concentrated to the
rear, reducing secondary light from the bottom and sides of
the lamp. We are striving for greater accuracy in lighting and
rapidity of preparatory work.

Lamp Base
Reflector

Pursuit of safety and creating a cold mirror from
2 the reflector
By making the reflector into cold mirror, allowing heat to pass
rearward and reflecting light forward, we have minimized the
volume of heat on objects in the studio. Every measure possible
has been taken for the sake of safety; the lamp base has been
given an arc protector and switch function, providing greater Operation Focus Vent
protection for the lamp base power source. This lamp has Handle Handle
reached an entirely new level of safety.

31
