01 MARUMO

BNQ2-500W
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.1m
Wattage 500W Minimum Throw Distance from Flammable Object 0.5m
Suitable Lamp JP100V500WBF Lamp Base R7s
JP100V500WCF Cable Length1.0m
Maximum Ambient Temperature 40°C Plug C-20P
Maximum Surface Temperature 85°C Body Material Steel
Body Weight 3.5kg Color Black
Tilt Angle/Suspended Use UP15° DN90° Color Frame 304mm×306mm
Tilt Angle/Stand Use UP90° DN10°

SPOTLIGHT & FLOODLIGHT
RIKURI 2

High-performance Ellipsoidal Spotlight RIKURI 2.
An ellipsoidal spotlight with superior optical qualities and operability. The combination of high-performance lenses and newly
designed reflectors achieve bright, crisp light distribution with a high uniformity ratio.

Any combination of lens tube and
1 lamp house
The RIKURI2 offers easy interchange ability
of lamp houses and lens tubes. A fixed-
focus tube can be replaced with a zoom
and a CDM lamp house can substitute for a Lamp House Halogen
halogen. And the change can be 500W / 575W / 650 W/ 750W
accomplished easily loosening just one bolt!
Bolt

Lens Tube 19 Lens Tube 26 Lens Tube 36 Lens Tube Lens Tube Lens Tube Lens Tube
50 Zoom N Zoom M Zoom W

2 Screw 2 Screw 1
Rugged lightweight magnesium alloy
The RIKURI2 lens tube is cast in a
magnesium alloy which combines rugged
durability and light weight. Although the unit is a Lens
multi-lens profile, it is well balanced and no Screw 3
heavier than a single-lens ellipsoidal spotlight.

Lens

Lens Tube Body Lens Tube Cover
3 Improved lens maintenance
High-performance lenses are particularly sensitive to dirt or grease
accumulation. RIKURI2 lens tubes are designed to permit easy access
to lenses for cleaning by loosening just three screws in fixed focus, five
screws in zoom model. Lenses are clearly marked to ensure correct
Modeled Lens Tube Cover (before coating) placement in reassembly.

36
