01 MARUMO

LED SPOTLIGHT & LED FLOODLIGHT
LEO/DDL

A lineup of LED downlights promoting low energy consumption.
The LEO round downlight and DDL downlight promote even greater reduction of energy in stage lighting equipment as
ceiling reflectory plate lights for stages.

LEO-WW-M
Voltage DC 48 V Minimum Safe Interval to Flammable Objec 0.1m
Light control range 0%~100% Minimum Throw Distance from Flammable Object 0.1m
Wattage 130 W Control Cable S-TKVVBS(P)12P × 0.2sq 1.5m
Control Channel 1ch Connector for Input MR-16M
Color Temperature 3000 K※1 Power source connector body C-20B
Color rendering typ. Ra95 Body Material Aluminum
Maximum Ambient Temperature 35 °C Color Black
Maximum Surface Temperature 80 °C Input Signa DMX512/1990※2
Body Weight 2.0kg Adaptive LED controller box LEP-1M1C-D
Attachment angular range UP 45°~DN 90° Option Trim Ring
※1 LED elements have a degree of variation among them; differences of light color

and brilliance can occur even for the same type.
※ 2 DMX512/1990 is the standard of USITT 1990.

LEP-1M1C-D
Voltage AC 100 V Voltage DC 48 V
Wattage 10 W(MAX140W) Fuse F-7142-125V-3A ※2
Operating Temperature Range 5° C~35° C Plug C -20P
Body Material 1.9kg Connector for DMX Input NC5MD-LX
Input Signal DMX512/1990 ※1 Through Connector for DMX NC5FD-LX
DMX Output 130W(MAX) Input Connector MR-16F
Control Channel 1ch Suitable Luminairy LEO-WW-M LEO-WW-N
※ 1 DMX512/1990 is the standard of USITT 1990.
※ 2 Spares are provided for parts built into the product.

ハロゲン電球とLEDの比較

Power consumption Annual CO2 emissions
LEDs consume a fifth of the LED annual CO2 emissions are
LED downlight DMX light control configuration power of halogen lights. reduced by 80% compared to
Running costs can be halogen lights. Their energy saving
The LED downlight light controls can be performed using seriously reduced. effectiveness is much heightened.
DMX512 signals. Light control using DMX512 signals requires a
dedicated DMX controller box.
Available controller boxes for the LEO round downlight are the
LEP- 1MIC-D, and for the DDL downlights the TLP-3M1C-D and Comparison of halogen lights with LEDs
TLP-3M3C-D. LEDs greatly reduce power consumption and annual CO2
emissions compared to conventional halogen lights.
