DDL-WW5
Voltage DC 26 V Minimum Safe Interval to Flammable Objec 0.1m
Light control range 0%~100% Minimum Throw Distance from Flammable Object 0.1m
Wattage 90 W Control Cable S-TKVVBS(P)12P × 0.2sq 1.2m
Control Channel 1ch Connector for Input MR-20M
Color Temperature 3000 K※1 Body Material Aluminum
Color rendering typ. Ra85 Color Black
Maximum Ambient Temperature 35 °C Input Signal DMX512/1990 ※2
Maximum Surface Temperature 60 °C Adaptive LED controller box TLP-3M1C-D
Body Weight 3.8kg Option Trim Ring(210mm × 210mm)
Attachment angular range 90°
※ 1 LED elements have a degree of variation among them; differences of light color and
brilliance can occur even for the same type.
※2 DMX512/1990 is the standard of USITT 1990.

DDL-CW5
Voltage DC 26 V Minimum Safe Interval to Flammable Objec 0.1m
Light control range 0%~100% Minimum Throw Distance from Flammable Object 0.1m
Wattage 90 W Control Cable S-TKVVBS(P)12P × 0.2sq 1.2m
Control Channel 1ch Connector for Input MR-20M
Color Temperature 6000 K※1 Body Material Aluminum
Color rendering typ. Ra70 Color Black
Maximum Ambient Temperature 35 °C Input Signal DMX512/1990 ※2
Maximum Surface Temperature 60 °C Adaptive LED controller box TLP-3M1C-D
Body Weight 3.8kg Option Trim Ring(210mm × 210mm)
Attachment angular range 90°
※ 1 LED elements have a degree of variation among them; differences of light color and
brilliance can occur even for the same type.
※2 DMX512/1990 is the standard of USITT 1990.

DDL-3C
Voltage DC 26 V Minimum Safe Interval to Flammable Objec 0.1m
Light control range 0%~100% Minimum Throw Distance from Flammable Object 0.1m
Wattage 90 W Control Cable S-TKVVBS(P)12P × 0.2sq 1.2m
Control Channel 3ch ※1 Connector for Input MR-20M
Color Temperature — ※2 Body Material Aluminum
Maximum Ambient Temperature 35 °C Color Black
Maximum Surface Temperature 60 °C Input Signal DMX512/1990 ※3
Body Weight 3.8kg Adaptive LED controller box TLP-3M3C-D
※ 1 1ch-R(Red), 2ch-G(Green), 3ch-B(Blue) Attachment angular range 90° Option Trim Ring(210mm × 210mm)
※2 LED elements have a degree of variation among them; differences of light color and brilliance can occur even for the same type.
※3 DMX512/1990 is the standard of USITT 1990.

DDL-3C
Model TLP-3M1C-D TLP-3M3C-D
Voltage AC 100 V Voltage DC 26 V
Wattage 10 W(MAX100W) Fuse F7161-125V-3A※ 3
Operating Temperature Range 5° C~ 35° C Plug C 型 20A(C -20P)
Body Material 3.0kg Connector for DMX Input NC5MD
Input Signal DMX512/1990 ※1 Through Connector for DMX NC5FD-LX
DMX Output 90W(MAX) Input Connector MR-20F
Control Channel 1ch 3ch ※2 Suitable Luminairy DDL-WW5 DDL-3C
DDL-CW5
