LEF2-6MH-6CB
Voltage AC 100 V LED stage light elevation 35°~100°
Light control range 0%~100% Fuse F7161-125V-5A※3
Wattage 200 W Cable Length 0.8m
Control Channel 6ch ※1 Plug C-20P
LED Color configuration R·G·B·A·CW·RB ※2 Power source connector body C-20B
Maximum Ambient Temperature 35 °C Body Material Steel · Aluminum
Maximum Surface Temperature 60 °C Color Black
Body Weight 12.3kg Connector for DMX Input NC5MD-LX
Minimum Safe Interval to Flammable Objec 0.1m Connector for DMX Output NC5FD-LX
Minimum Throw Distance from Flammable Object 0.1m Input Signal DMX512/1990 ※4
※ 1 1 1ch-R(Red), 2ch-G(Green), 3ch-B(Blue), 4ch-A(Amber), 5ch-CW(Cool White),
6ch-RB(Royal Blue)
※ 2 LED elements have a degree of variation among them; differences of light color
and brilliance can occur even for the same type.
※3 Spares are provided for parts built into the product.
※4 DMX512/1990 is the standard of USITT 1990.

LEF-6MUH-6CR
Voltage AC 100 V LED stage light elevation 35°~100°
Light control range 0%~100% Fuse F7161-125V-5A※3
Wattage 200 W Cable Length 0.8m
Control Channel 6ch ※1 Plug C-20P
LED Color configuration R·G·B·A·CW·DR ※2 Power source connector body C-20B
Maximum Ambient Temperature 35 °C Body Material Steel · Aluminum
Maximum Surface Temperature 60 °C Color Black
Body Weight 13.2kg Connector for DMX Input NC5MD-LX
Minimum Safe Interval to Flammable Objec 0.1m Connector for DMX Output NC5FD-LX
Minimum Throw Distance from Flammable Object 0.1m Input Signal DMX512/1990 ※4
※ 1 1ch-R(Red), 2ch-G(Green), 3ch-B(Blue), 4ch-A(Amber), 5ch-CW(Cool White),
6ch-DR(Dark Red)
※ 2 LED elements have a degree of variation among them; differences of light color
and brilliance can occur even for the same type.
※3 Spares are provided for parts built into the product.
※4 DMX512/1990 is the standard of USITT 1990.

LEF2-6MH-6CR
Voltage AC 100 V LED stage light elevation 35°~100°
Light control range 0%~100% Fuse F7161-125V-5A※3
Wattage 200 W Cable Length 0.8m
Control Channel 6ch ※1 Plug C-20P
LED Color configuration R·G·B·A·CW·DR ※2 Power source connector body C-20B
Maximum Ambient Temperature 35 °C Body Material Steel · Aluminum
Maximum Surface Temperature 60 °C Color Black
Body Weight 12.3kg Connector for DMX Input NC5MD-LX
Minimum Safe Interval to Flammable Objec 0.1m Connector for DMX Output NC5FD-LX
Minimum Throw Distance from Flammable Object 0.1m Input Signal DMX512/1990 ※4
※ 1 1ch-R(Red), 2ch-G(Green), 3ch-B(Blue), 4ch-A(Amber), 5ch-CW(Cool White),
6ch-DR(Dark Red)
※ 2 LED elements have a degree of variation among them; differences of light color
and brilliance can occur even for the same type.
※3 Spares are provided for parts built into the product.
※4 DMX512/1990 is the standard of USITT 1990.

25
