04 DESISTI

≫ Supplied with stainless steel wireguard & UV safety glass ≫ Silent high voltage igniter to operate from electronic or magnetic
≫ Supplied with a cool grip rear handle ballasts
≫ Can be fired locally from the head or remotely from the ballast or via ≫ Weatherproof on/off push buttons
DMX ≫ IP23 rain tested
≫ Hinged lens door with quick release latch and pivoting ear for easy ≫ Cut-off micro-switches located on UV safety glass, lens door and lamp
loading of five different drop-in lenses without removing barndoor or lock
other front-mounted accessories LAMP 4000w Maximum
≫ External knob activated lamp release under locking cover ≫ High voltage insulated G38 bi-pin socket for single ended HMI lamps
≫ Digital non-resetting universal hour counter (see table for suitable lamps)
≫ assembled to the side of the igniter box ≫ Capable of hot re-strike
≫ Heavy duty tubular skid ≫ Collar clamping holds lamp firmly without stressing the electrical
≫ Reinforced steel tube yoke with 1” male spigot attached for C-clamp contacts
and side mounted cable OPTICAL/ FOCUS MECHANISM
≫ holding loop ≫ Special bi-metallic clad aluminum reflector for high degree of reflectivity
≫ Clutch activated T-handle for secure, single hand operation and thermal resistance for long life
≫ UL Listed ≫ Beam intensity controlled by a rear focus knob
ELECTRICAL 115-240V, 50/60Hz ≫ Drop-in lenses include: Narrow spot, medium flood, wide flood, extra
≫ Six foot (6’) attached head to ballast cable wide flood and frosted Fresnel

PHOTOMETRIC DATA
Values measured with MSR 2500 HR and MSR 4000 HR Values measured with MSR 2500 HR and MSR 4000 HR
METERS FEET
TYPICAL DISTANCES 6 mt 12 mt 18 mt 24 mt TYPICAL DISTANCES 20’ 40’ 60 80
LENS TYPE Candle Power Lux LENS TYPE Candle Power Footcandles
4 kW 8.500.000 236.111 59.028 26.235 14.757 4 kW 8.500.000 21.222 5.306 2.358 1.327
NO Lens NO Lens
2,5 kW 7.100.000 197.222 49.306 21.914 12.326 2,5 kW 7.100.000 17.727 4.432 1.970 1.109
VNSP 4 kW 2.250.000 62.500 15.625 6.944 3.906 VNSP 4 kW 2.250.000 5.618 1.404 1.970 351
Frosted 2,5 kW 1.500.000 41.667 41.667 4.630 2.604 Frosted 2,5 kW 1.500.000 3.745 936 416 234
NSP Narrow 4 kW 1.750.000 48.611 12.153 5.401 3.038 NSP Narrow 4 kW 1.750.000 4.369 1.092 485 273
Rect. Pr. 2,5 kW 1.200.000 33.333 8.333 3.704 2.083 Rect. Pr. 2,5 kW 1.200.000 2.996 749 333 187
MF Wide 4 kW 710.000 19.722 4.931 2.191 1.233 MF Wide 4 kW 710.000 1.773 443 197 111
Rect. Pr. 2,5 kW 430.000 11.944 2.986 1.327 747 Rect. Pr. 2,5 kW 430.000 1.074 268 119 67
WF Square 4 kW 500.000 13.889 3.472 1.543 868 WF Square 4 kW 500.000 1.248 312 139 78
Dimples 2,5 kW 320.000 8.889 2.222 988 556 Dimples 2,5 kW 320.000 799 200 89 50
Frosted 4 kW 155.000 4.306 1.076 478 269 Frosted 4 kW 155.000 387 97 43 24
Fresnel 2,5 kW 110.000 3.056 764 340 191 Fresnel 2,5 kW 110.000 275 69 31 17
F.C. AT ANY DISTANCE = LUX. AT ANY DISTANCE = F.C. AT ANY DISTANCE = LUX. AT ANY DISTANCE =
BEAM ANGLE Candle Power : Candle Power : BEAM ANGLE Candle Power : Candle Power :
(50% of center value) (50% of center value)
(distance in ft)2 (distance in ft)2 (distance in ft)2 (distance in ft)2
BEAM SIZE (W x H in feet) BEAM SIZE (W x H in feet)
No Lens 6° 0,6 1,3 1,9 2,5 No Lens 6° 2.1 4.2 6.3 8.4
VNSP Frosted 15° 1,2 3,2 4,7 6,3 VNSP Frosted 15° 5.3 10.5 15.8 21.1
NSP Narrow Rect. Pr. 26°x12° 2,8x1,3 5,5x2,5 8,3x3,8 11,1x5,0 NSP Narrow Rect. Pr. 26°x12° 9.2x4.2 18.5x8.4 27.7x12.6 36.9x16.8
MF Wide Rect. Pr. 50°x22°° 5,3x2,3 11,2x4,7 16,8x7,0 22,4x9,3 MF Wide Rect. Pr. 50°x22°° 18.7x7.8 37.3x15.6 56.0x23.3 74.6x31.1
WF Square Dimples 27° 2,9 5,8 8,6 11,5 WF Square Dimples 27° 9.6 19.2 28.8 38.4
Frosted Fresnel 42° 4,6 9,2 13,8 18,4 Frosted Fresnel 42° 15.4 30.7 46.1 61.4

ORDERING INFORMATION
Mod Description
HMI PAR supplied with attached 6’ head to ballast cable & connector and
2340 tubular steel yoke with 1’’ spigot
System supplied with detachable 6’ head to ballast cable & connector,
tubular steel yoke with 1” spigot, four leaf medium barndoor, set of 5
2340.600/S lenses, fly case for lenses & DEB 2500/4000w dual flicker free electronic
ballast & 25’ extension cable
System supplied with attached 6’ head to ballast cable & connector,
tubular steel yoke with 1” spigot, four leaf medium barndoor, set of 5
2340.610/S/L lenses, fly case for lenses, DEB 2500/4000w dual flicker free electronic
ballast, 25’ extension cable and 4000w MSR lamp
Kit supplied with attached 6’ head to ballast cable & connector, tubular
steel yoke with 1” spigot, four leaf medium barndoor, set of 5 lenses, fly
2340.690/K/H/L case for lenses, 25’ extension cable, four piece scrim set, 4000w MSR
lamp and fly case for complete kit—no ballast

144
