04 DESISTI

ACCESSORIES TYPES & MODEL NUMBERS
DESCRIPTION OF PART Self weight in Kg.
1 TELESCOPIC POLE: 2 choices of height ranges available:
A = 1,4 m. closed – 4 m. fully extended (3 risers) 2,6
B = 1,9 m. closed – 6,5 m. fully extended (3 risers) 3,1
1 Off-Set Handle for better grip when using the MOTORIZED TOOL 0,1
1 REDUCER-MULTPLIER Adapter 1
≫15 POSITIONS SELECTABLE TORQUE LIMITER 1,5
≫2 SELECTABLE SPEED ≫1 BATTERY Nickel-Metal idrate 3.0 Ah
1 BATTERY CHARGER with special function to avoid memory effect on batteries 0.3
1 SPARE BATTERY Lithium 2,6 Ah 14,4 V 0.5
1 TRANSPORT CASE for POWER TOOL & ACCESSORIES 0.5
1 MANUAL CRANK HANDLE 1,2
WEIGHT OF SYSTEM IN MODE 1 - POLE TYPE A (Short range) 4,2
WEIGHT OF SYSTEM IN MODE 1 - POLE TYPE B (Long range) 4,7
WEIGHT OF SYSTEM IN MODE 2 - POLE TYPE A (Short range) 5,2
WEIGHT OF SYSTEM IN MODE 2 - POLE TYPE B (Long range) 5,7
WEIGHT OF SYSTEM IN MODE 3 - POLE TYPE A (Short range) 3,9
WEIGHT OF SYSTEM IN MODE 3 - POLE TYPE B (Long range) 4,4

Dual Power Daylight
REMBRANDT 6/12 kW

FEATURES
CONSTRUCTION:
≫Fixture housing in STAINLESS STEEL (INOX).
FINISHING:
≫ SAND BLASTED AND CHEMICALLY TREATED MATT STAINLESS
STEEL (INOX).
WEIGHT REDUCTION & OPTIMIZED PHOTOMETRICS:
≫ The new design permits to reduce the weight of the unit from 48kg.
Down to 43 kg.
≫ Exceptional photometrics, the Rembrandt 6/12 kW is a good
alternative to 18 kW double ended lamps Fresnel fixtures
WEIGHT 43 Kg.
Mod. 2570 DISCHARGE LAMP TYPES:
≫Single ended Hot Re-strike either 6 kW or 12 kW discharge lamps
DOUBLE POWER
≫ QUICK ACTION TOOL FREE lamp holder mechanism to set the
fixture for either 6 or 12 kW lamp use.
INNOVATIVE PATENT PENDING IGNITER SYSTEM:
≫ TWO STAGE IGNITER, eliminating the need of HIGH VOLTAGE
isolated movable internal cable.
≫SILENT operation of the IGNITER also in FLICKER FREE mode.

PHOTOMETRIC DATA REMBRANDT 6/12 kW
Values measured with: MSR 6000 HR, KOTO 12000W 500 mm. Diam. Fresnel Lens
FEET METERS
TYPICAL DISTANCES 25’ 50’ 75’ 80’ 6,0 12 18 24
LIGHT CENTER VALUES Candle Power Footcandles Lux
6 kW 4.350.000 6.960 1.740 773 435 67.969 16.992 7.552 4.248
SPOT
12 kW 5.800.000 9.280 2.320 1.031 580 90.625 22.656 10.069 5.664
6 kW 275.000 440 110 49 28 4.297 1.074 477 269
FLOOD
12 kW 365.600 585 146 65 37 4.297 1.428 635 357
F.C. AT ANY DISTANCE = Candle Power : LUX. AT ANY DISTANCE =
BEAM ANGLE (50% of center value) (distance in ft)2 Candle Power : (distance in ft)2
BEAM SIZE (W x H in feet) BEAM SIZE(W x H in meters)
SPOT 6,0° 2.6’’ 5.2’ 7.9’ 10.5’ 0,8 mt 1,7 mt 2,5 mt 3,4 mt
FLOOD 64,0° 31.2’ 62.5’ 93.7’ 125.0’ 10,0 mt 20,0 mt 30,0 mt 40,0 mt

142
