04 DESISTI

PHOTOMETRIC DATA
Values measured with MSR 6000 HR AND KOTO 12000 W Values measured with MSR 6000 HR AND KOTO 12000 W
METERS FEET
TYPICAL DISTANCES 8 mt 16 mt 24 mt 32 mt TYPICAL DISTANCES 25’ 50’ 75’ 100’
LENS TYPE Candle Power Lux LENS TYPE Candle Power Footcandles
12 kW 14.850.000 232.031 58.008 25.781 14.502 12 kW 14.850.000 23.698 5.940 2.640 1.485
NO Lens NO Lens
6 kW 11.250.000 175.781 43.945 19.531 10.986 6 kW 11.250.000 17.953 4.500 2.000 1.125
VNSP 12 kW 10.053.000 157.078 39.270 17.453 9.817 VNSP 12 kW 10.053.000 16.043 4.021 1.787 1.005
Frosted 6 kW 7.537.500 117.773 29.443 13.086 7.361 Frosted 6 kW 7.537.500 12.028 3.015 1.340 754
NSP Narrow 12 kW 4.414.500 68.977 17.244 7.664 4.311 NSP Narrow 12 kW 4.414.500 7.045 1.766 785 441
Rect. Pr. 6 kW 2.837.250 44.332 11.083 4.926 2.771 Rect. Pr. 6 kW 2.837.250 4.528 1.135 504 284
MF Wide 12 kW 1.536.075 24.001 6.000 2.667 1.500 MF Wide 12 kW 1.536.075 2.451 614 273 154
Rect. Pr. 6 kW 945.000 14.766 3.691 1.641 923 Rect. Pr. 6 kW 945.000 1.508 378 168 95
WF Square 12 kW 824.625 12.885 3.221 1.432 805 WF Square 12 kW 824.625 1.316 330 147 82
Dimples 6 kW 504.000 7.885 1.969 875 492 Dimples 6 kW 504.000 804 202 90 50
Frosted 12 kW 280.350 4.380 1.095 487 274 Frosted 12 kW 280.350 447 112 50 28
Fresnel 6 kW 155.250 2.426 606 270 152 Fresnel 6 kW 155.250 248 62 28 16
F.C. AT ANY DISTANCE = LUX. AT ANY DISTANCE = F.C. AT ANY DISTANCE = LUX. AT ANY DISTANCE =
BEAM ANGLE Candle Power : Candle Power : BEAM ANGLE Candle Power : Candle Power :
(50% of center value) (50% of center value)
(distance in ft)2 (distance in ft)2 (distance in ft)2 (distance in ft)2
BEAM SIZE (W x H in feet) BEAM SIZE (W x H in feet)
No Lens 7,5° 1,0 2,1 3,1 4,2 No Lens 7,5° 3.3 6.6 9.8 13.1
VNSP 7,5° 1,0 2,1 3,1 4,2 VNSP Frosted 7,5° 3.3 6.6 9.8 13.1
NSP Narrow Rect. Pr. 15°x 9° 2,1 x 1,3 4,2 x 2,5 6,3x 3,,8 8,4 x 5,0 NSP Narrow Rect. Pr. 15°x9° 6.6x3.9 13.2x7.9 19.7x11.8 26.3x15.7
MF Wide Rect. Pr. 30°x 15° 4,3 x 2,1 8,6 x 4,2 12,9 x 6,3 17,1 x 8,,4 MF Wide Rect. Pr. 30°x15° 13.4x6.6 26.8x13.2 40.2x19.7 53.6x26.3
WF Square Dimples 34,5° 5,0 9,9 14,9 19,9 WF Square Dimples 34,5° 15.5 31.1 46.6 62.1
Frosted Fresnel 30° 4,3 8,6 12,9 17,1 Frosted Fresnel 30° 13.4 26.8 40.2 53.6

ORDERING INFORMATION
Mod Description
2370 HMI PAR supplied with tubular steel yoke with 1” spigot
System supplied with 25’ head to ballast cable & connector, tubular steel yoke with 1” spigot, four leaf barndoor, set of 5 lenses, fly case for
2370.600/S lenses, DEB 6/12kW dual flicker free electronic ballast & fly case for DEB 6/12kW dual ballast
System supplied with 25’ head to ballast cable & connector, tubular steel yoke with 1” spigot, four leaf barndoor, set of 5 lenses, fly case for
2370.610/S/L lenses, DEB 6/12kW dual flicker free electronic ballast and 12000w MSR lamp
Kit supplied with 25’ head to ballast cable & connector, tubular steel yoke with 1” spigot, four leaf barndoor, four piece scrim set, 12000w
2370.690/K/H/L MSR lamp and fly case for complete kit—no ballast or lenses

ACCESSORIES
Mod Description
DEB 6000/12000w dual flicker free electronic ballast 185/265v, 50/60Hz,
2555.100 low noise and 35% dimming capability, with 6’ detachable main cable
(MIL connector)
496.100 Four leaf rotating barndoor
497.100 Colour frame
499.100 Four piece stainless steel scrim set
Set of 5 lenses with ring & handle including: Narrow spot, medium flood,
2375.200 wide flood, extra wide flood & frosted fresnel
2378.100 Fly case for 5 piece lens set
2378.180 Fly case for 2370.690/K/H/L Kit
2555.601 Fly case for dual DEB 6000/12000w ballast
2451.100 Cable Head to Ballast 12000w, 25’
2451.200 Cable Head to Ballast 12000w, 50’
DGP-B250X Super wind-up stainless steel stand with braked hard wheels
