OVERVIEW                                              FEATURES
                     With the important success in the Market of DE SISTI LED FRESNELS and   The Mini SPIDER is a Pole Operated Pantograph, featuring a
                     ENERGY EFFICIENT LIGHTS, we have experienced a very high percentage   unique scissor arm assembly with a patented stabilizing system
                     of newer Studios using more DMX Controlled devices and really getting the   built in a special structural fiber material, in order to provide a
                     flexibility and benefit of being able to position the different FIXTURES   steady support for the lighting fixtures and allowing also the
                     anywhere within the Studio Area.                      assembling of an horizontal pipe or rail at bottom to hang more
                     The MINI SPIDER is the Lightest Weight and most compact Pole   than one instrument.
                     Operated Pantograph in the market for 30 kg. lifting capacity, with   The following are the Mini SPIDER main features:
                     exceptional stability of the movable part:            ≫30 kg. S.W.L. (Safe Working Load) which is the maximum net
                     A Manual Suspension with exclusive Special Fiber Pantograph Arms, a   lifting capacity of the machine, with Static and Dynamic Self
                     built in cable management system and TOP/BOTTOM offset load   Sustaining Gearbox, having costant resisting Torque, for either
                     Stabilizers, the MINI SPIDER is a unique product for stable support of the   Manual or Motorized Pole activation.
                     Lighting fixture.                                     ≫ 2 independent STAINLESS METAL BANDS 20x0,3 cross
                     The special Shape of the Arms provide additional stability to the moving   section, minimum breaking load per band 948 kg. Rounded
                     part of the pantograph, yet the fact that they are built in a special structural   edges.
                     fiber material make this pantograph the lightest weight in the industry (the   ≫ Mechanical TOP and BOTTOM Limits, Scissor Arms
                     Self weight of a 4 m. net extension MINI SPIDER, for 6 m. hanging heights,   Stabilization and PATENTED STABILIZING GEARED Hinges to
                     complete with Mains and DMX Load circuits is only 11,5 kg.).  reduce Lateral sway and permit off centred loading.
                     The following HIGHLIGHTS are representing the innovation introduced by   ≫ Structural Fiber SCISSOR ARMS for stability of the moving part
                     the MINI SPIDER:                                        and minimized self- weight of the pantograph. Each hinge is
                     1. A stable support at any height of the lighting fixture.  junction by screws, self-locking nuts and brass spacing rims
                     2. A special cable management to keep electrical conductor within the   for accurate control and functionality.
                     scissor arms                                          ≫ Bottom moving part with 1 circuit 20A POWERCON and 1
                     structure and avoid stress on cables without severe bending radius.  DMX on XLR5P. Electrical Cables are contained within the
                     3. An extremely contained Self Weight of 11,5 kg. (to minimize loading the   Scissor Arm for protection and to minimize the bending stress
                     Studio ceiling). 4. Compact height when fully closed to maximize the use of   on the conductors.
                     the Studio height.                                    ≫ Very Small Height occupancy when fully retracted, to maximize
                     5. Ability to lift 30 kg. net, that can carry the majority of lighting fixtures for   the studio height use.
                     studio use.                                           ≫ Two Types of NET VERTICAL EXTENSION :
                     6. Built In Mains and DMX Distribution on the moving part.      Type1=2m.(appropriateforaFixingheightofmax.4m.)–
                     7. Compatible with the all D RAIL Range for full flexibility of positioning the   ClosedDimension0,63m.
                     Lighting Fixture.                                        Type2=4m.(appropriateforaFixingheightofmax.6m.)–
                     8. Contained Pricing.                                 ClosedDimension0,72m.
                     The MINI SPIDER is the product that makes the Manual (Pole Operated)   ≫Either B.S. or DIN Spigot at TOP and Receiver at bottom.
                     positioning of your studio LIGHTS affordable in costs and provide the best   ≫ Easy install of “D” RAIL OR 48 mm. DIAMETER PIPE of
                     flexibility to the lighting system.                     maximum 1 m. length at bottom, for multiple fixtures hanging
                     Energy efficiency is also about being able to optimally locate your lighting   on the Mini SPIDER.
                     fixtures to obtain the best picture.                  ≫Safety Certified by TUV




                     EXTENSION DIAGRAM
                     Two Types of MINI SPIDER with the
                     respective NET VERTICAL EXTENSION :
                     Type1=2m.(appropriateforaFixingheightofm
                     ax.4m.)–ClosedDimension0,63m. o
                     Type2=4m.(appropriateforaFixingheightofm
                     ax.6m.)–ClosedDimension0,72m.
