01 MARUMO

PEQ-100W12L
Model PEQ-100W12L-3C PEQ-100W12L-3CD PEQ-100W12L-4C PEQ-100W12L-4CD
Voltage AC100V AC100V AC100V AC100V
Total Wattage 1200W MAX 1200W MAX 1200W MAX 1200W MAX
Suitable Lamp JD100V85W·NP/E×12 JD100V85W·NP/E×12 JD100V85W·NP/E×12 JD100V85W·NP/E×12
Circuit 3 3 4 4
Maximum Ambient Temperature 40° 40° 40° 40°
Maximum Surface Temperature 85°C 85°C 85°C 85°C
Body Weight 9.7kg 9.7kg 10.5kg 10.5kg
Minimum Safe Interval to Object 0.1m 0.1m 0.1m 0.1m
Minimum Throw Interval to Object 0.4m 0.4m 0.4m 0.4m
Reflector Aluminum Aluminum Aluminum Aluminum
Lamp Base E11 E11 E11 E11
Cable Length 0.55m 0.55m 0.55m 0.55m
Plug C-20P(Stage Left) C-20P(Stage Right) C-20P(Stage Left) C-20P(Stage Right)
Connector C-20B(Stage Right) C-20B(Stage Left) C-20B(Stage Right) C-20B(Stage Left)
Body Material Steel Steel Steel Steel
Color Ivory Ivory Ivory Ivory
Color Frame 146mm×112mm 146mm×112mm 146mm×112mm 146mm×112mm

F-60W12L
Model PEQ-100W12L-3C PEQ-100W12L-3CD PEQ-100W12L-4C PEQ-100W12L-4CD
Voltage AC100V AC100V AC100V AC100V
Total Wattage 720W MAX 720W MAX 720W MAX 720W MAX
Suitable Lamp LF100V60W×12 LF100V60W×12 LF100V60W×12 LF100V60W×12
Circuit 3 3 4 4
Maximum Ambient Temperature 40° 40° 40° 40°
Maximum Surface Temperature 60°C 60°C 60°C 60°C
Body Weight 13.0kg 13.0kg 13.6kg 13.6kg
Minimum Safe Interval to Object 0.1m 0.1m 0.1m 0.1m
Minimum Throw Interval to Object 0.2 m 0.2 m 0.2 m 0.2 m
Reflector Aluminum Aluminum Aluminum Aluminum
Lamp Base E26 E26 E26 E26
Cable Length 0.55m 0.55m 0.55m 0.55m
Plug C-20P(Stage Left) C-20P(Stage Right) C-20P(Stage Left) C-20P(Stage Right)
Connector C-20B(Stage Right) C-20B(Stage Left) C-20B(Stage Right) C-20B(Stage Left)
Body Material Steel Steel Steel Steel
Color Ivory Ivory Ivory Ivory
Color Frame 144mm×137mm 144mm×137mm 144mm×137mm 144mm×137mm

PE-60W12L
Model PE-60W12L-3C PE-60W12L-3CD PE-60W12L-4C PE-60W12L-4CD
Voltage AC100V AC100V AC100V AC100V
Total Wattage 720W MAX 720W MAX 720W MAX 720W MAX
Suitable Lamp LF100V60W×12 LF100V60W×12 LF100V60W×12 LF100V60W×12
Circuit 3 3 4 4
Maximum Ambient Temperature 40° 40° 40° 40°
Maximum Surface Temperature 60°C 60°C 60°C 60°C
Body Weight 11.8kg 11.8kg 12.3kg 12.3kg
Minimum Safe Interval to Object 0.1m 0.1m 0.1m 0.1m
Minimum Throw Interval to Object 0.2 m 0.2 m 0.2 m 0.2 m
Reflector Aluminum Aluminum Aluminum Aluminum
Lamp Base E26 E26 E26 E26
Cable Length 0.5m 0.5m 0.5m 0.5m
Plug C-20P(Stage Left) C-20P(Stage Right) C-20P(Stage Left) C-20P(Stage Right)
Connector C-20B(Stage Right) C-20B(Stage Left) C-20B(Stage Right) C-20B(Stage Left)
Body Material Steel Steel Steel Steel
Color Ivory Ivory Ivory Ivory
Color Frame 144mm×137mm 144mm×137mm 144mm×137mm 144mm×137mm

50
