01 MARUMO

BORDER & HORIZONT LIGHTS
QCU/QCL/UHQ/LHQ

QCL/QCU with new type
1 reflector
The Cyclorama Light series produces an The QCL/QCU high-power
even distribution of bright light over a wide models use a newly designed
area of the cyclorama. reflector to provide smooth light
The top cyclorama lights shine from above the stage where distribution to the central part of
the horizon, offering more uniform
they are hung. The bottom cyclorama lights illuminate from the lighting and making the horizon
floor of the stage. All of the lights in this series, the QCU, QCL, more beautiful than conventional
UHQ, and LHQ, provide a bright band of light over a large area. models. The single model can be
Every performance space can use these cyclorama lights for a used with 300W to 1000W lamps
wide variety of coverage depending on capacity and size. and the linked model with 200W
to 500W lamps.

2 4 lamps
UHQ and LHQ - compact and lightweight
Wide variation from 100W to 1000W
The UHQ and the LHQ are available with three-color and
four-color wiring in twelve-light connectable modules with the The UHQ and LHQ models mount the lamps of
following wattage: 85W, 100W, 150W and 200W. These are 85W to 200W while the QCU, QCU models
convenient as portable cyclorama lights as well as suitable for mount from 300W to 1000W, and QCL models
small venues, exhibitions, or multipurpose use. mount from 200W to 1000W.

Model A Single-type
3
For the upper cyclorama light QCU lower cyclorama light QCL,
the stage light line-up consists of the Model A single-type.

Upper Horizont Light Lower Horizont Light
QCU5A φ42.7mm pipe mounting QCU5A Floor setting

QCU5A-300W / QCU5A-500W / QCU5A-750W※ / QCU5A-1000W※
Model QCU5A-300W QCU5A-300W-LG QCU5A-500W QCU5A- 500W-LG QCU5A-750W※ QCU5A-750W-LG※ QCU5A-1000W※ QCU5A-1000W-LG※
Voltage 100V 100V 100V 100V 100V 100V 100V 100V
Suitable Lamp JP100V500WBF JP100V500WBF JP100V750WBF JP100V750WBF JP100V1000WBF JP100V1000WBF
J100V300WF J100V300WF JP100V500WCF JP100V500WCF JP100V750WCF JP100V750WCF JP100V1000WCFJP100V1000WCF
Maximum Ambient Temperature 40° 40° 40° 40° 40° 40° 40° 40°
Maximum Surface Temperature 100° 100° 115° 115° 150° 150° 170° 170°
Body Weight 2.5kg 2.6kg 2.5kg 2.6kg 2.5kg 2.6kg 2.5kg 2.6kg
Minimum Safe Interval to Object 0.2m 0.2m 0.2m 0.2m 0.3m 0.3m 0.3m 0.3m
Minimum Throw Interval to Object 0.2m 0.2m 0.2m 0.2m 0.2m 0.2m 0.2m 0.2m
Reflector Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum

46
