FG-60W12L FG-60W12L
Model FG-60W12L-2C FG-60W12L-2CD Model CH-60W12L-2C CH-60W12L-2CD
Voltage AC100V AC100V Voltage AC100V AC100V
Total Wattage 720W MAX 720W MAX Total Wattage 720W MAX 720W MAX
Suitable Lamp LF100V60W×12 LF100V60W×12 Suitable Lamp LF100V60W×12 LF100V60W×12
Circuit 2 2 Circuit 2 2
Maximum Ambient Temperature 40° 40° Maximum Ambient Temperature 40° 40°
Maximum Surface Temperature 75°C 75°C Maximum Surface Temperature 60°C 60°C
Body Weight 12.1kg 12.1kg Body Weight 12.6kg 12.6kg
Minimum Safe Interval to Object 0.1m 0.1m Minimum Safe Interval to Object 0.1m 0.1m
Minimum Throw Interval to Object 0.2 m 0.2 m Minimum Throw Interval to Object 0.2 m 0.2 m
Reflector Aluminum Aluminum Reflector Aluminum Aluminum
Lamp Base E26 E26 Lamp Base E26 E26
Cable Length 0.6m 0.6m Cable Length 0.45m 0.45m
Plug C-20P(Stage Left) C-20P(Stage Right) Plug C-20P(Stage Left) C-20P(Stage Right)
Connector C-20B(Stage Right) C-20B(Stage Left) Connector C-20B(Stage Right) C-20B(Stage Left)
Body Material Steel Steel Body Material Steel Steel
Color Ivory Ivory Color Ivory Ivory
Color Frame 144mm×137mm 144mm×137mm Color Frame 144mm×137mm 144mm×137mm
Option Strengthened Glass Strengthened Glass

BORDER & HORIZONT LIGHTS
CQ/CT

Simplified, versatile strip lights.
A lightweight, easy to handle striplight, MARUMO’s STRIP LIGHT series has many practical applications,
from set mount lighting to footlights. Designed to match any performance space.

Small and easy to handle
1
These lights can be used to
meet a wide variety of
applications, either as easily
moved footlights, cyclorama
lights, or suspended lights for
partial lighting.

2 Bulb and fixture options CQ-100W4L / CQ-100W8L / CQ-100W12L CQ-100W12L-3C CQ-100W12L-3CD
The CQ with 85W bulb and
CQ-100W4L-2CX
CQ-100W8L-2CX CQ-100W12L-2CX
Model
the CT with a 60W bulb are Voltage AC100V AC100V AC100V AC100V AC100V
available in four-, eight-, and Total Wattage 400W MAX 800W MAX 1200W MAX 1200W MAX 1200W MAX
twelve-light fixtures. Suitable Lamp JD100V85W·NP/E×4 JD100V85W·NP/E×8 JD100V85W·NP/E×12JD100V85W·NP/E×12JD100V85W·NP/E×12
Circuit 2 2 2 3 3
Maximum Ambient Temperature 40° 40° 40° 40° 40°
Maximum Surface Temperature 145°C 145°C 145°C 145°C 145°C
Body Weight 2.3kg 3.5kg 5.0kg 5.6kg 5.6kg
