BORDER & HORIZONT LIGHTS
BCQ
Borderlight using halogen bulb
The BCQ is a borderlight using halogen bulb as a light source. It can be custom designed and manufactured to suit the
depth and frontage of a stage.
BCQ-100W9L / BCQ-150W9L / BCQ-200W9L
Model BCQ-100W9L-3C BCQ-100W9L-3CT BCQ-150W9L-3C BCQ-150W9L-3CT BCQ-200W9L-3C BCQ-200W9L-3CT
Voltage AC100V AC100V AC100V AC100V AC100V AC100V
Total Wattage 900W MAX 900W MAX 1350W MAX 1350W MAX 1800W MAX 1800W MAX
Suitable Lamp JD100V85W·NP/E×9 JD100V85W·NP/E×9 JD100V130W·NP/E×9 JD100V130W·NP/E×9 JCV100V200WGS×9 JCV100V200WGS×9
Circuit 3 3 3 3 3 3
Maximum Ambient Temperature 40°C 40°C 40°C 40°C 40°C 40°C
Maximum Surface Temperature 65°C 65°C 75°C 75°C 85°C 85°C
Body Weight 10.2kg 10.5kg 10.2kg 10.5kg 10.2kg 10.5kg
MinimumSafeIntervaltoFlammableObject 0.1m 0.1m 0.1m 0.1m 0.1m 0.1m
Minimum Throw Distance from Flammable Object 0.2m 0.2m 0.4m 0.4m 0.5m 0.5m
Reflector Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum
Lamp Base E11 E11 E11 E11 E11 E11
Body Material Steel Steel Steel Steel Steel Steel
Color Black Black Black Black Black Black
Color Frame 195mm×195mm 195mm×195mm 195mm×195mm 195mm×195mm 195mm×195mm 195mm×195mm
Others Terminal Terminal Terminal
Model BCQ-100W9L-3C BCQ-100W9L-3CT BCQ-150W9L-3C BCQ-150W9L-3CT BCQ-200W9L-3C BCQ-200W9L-3CT
Voltage AC100V AC100V AC100V AC100V AC100V AC100V
Total Wattage 900W MAX 900W MAX 1350W MAX 1350W MAX 1800W MAX 1800W MAX
Suitable Lamp JD100V85W·NP/E×9 JD100V85W·NP/E×9 JD100V130W·NP/E×9 JD100V130W·NP/E×9 JCV100V200WGS×9 JCV100V200WGS×9
Circuit 4 4 4 4 4 4
Maximum Ambient Temperature 40°C 40°C 40°C 40°C 40°C 40°C
Maximum Surface Temperature 65°C 65°C 75°C 75°C 85°C 85°C
Body Weight 11.9kg 12.2kg 11.9kg 12.2kg 11.9kg 12.2kg
MinimumSafeIntervaltoFlammableObject 0.1m 0.1m 0.1m 0.1m 0.1m 0.1m
Minimum Throw Distance from Flammable Object 0.2m 0.2m 0.4m 0.4m 0.5m 0.5m
Reflector Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum
Lamp Base E11 E11 E11 E11 E11 E11
Body Material Steel Steel Steel Steel Steel Steel
Color Black Black Black Black Black Black
Color Frame 195mm×195mm 195mm×195mm 195mm×195mm 195mm×195mm 195mm×195mm 195mm×195mm
Others Terminal Terminal Terminal
