This is an adapter to fit previous products such as EPQ or VS to current products such as EQS or EDM.

EMOPT Conversion Adapter
Model EMOPT-1 EMOPT-2 EMOPT-3 EMOPT-4
Body Materia Steel Steel Steel Steel
Color Black Black Black Black
Body Weight 0.8kg 0.9kg 0.5kg 0.5kg
Suitable Light Source EQS/EMS EPQ — —
Suitable Machine Old Model Current Model Old Model Current Model
Suitable Objective — — OL/OL-S SDA/SDZ

⁕ Patterns
PVD Series
This pattern series is mounted in the VSD disc machine.

PND Series
This pattern series is mounted in the NCD double machine. There
are two materials: stainless steel (S type), and glass (N type).

P4 Series
This series of 4 x 5 patterns is mounted in the TPD turret plate.

Model PVD Series(除く 101S,107S) PVD-101S PVD-107S PND-XXXS PND-XXXN P4 Series
Size φ465mm W178mm×H170mm φ148mm φ148mm W125mm×H100mm
Suitable Effect Machine VSD3 VSD3 NCD3 NCD3 TPD3
Body Material Stainless Steel Stainless Steel Stainless Steel Glass Stainless Steel

EFFECT
NAE

Reproduce realistic wave images.
This unit projects a ripple effect on the cyclorama. The unit was designed to provide wide coverage
so that a wave effect can be projected over a broad area.

Two 500W halogen ulight bulbs are mounted
1 2 Variable speed control
By the light through the cutout patterns of the drum, NAE effect
Speed of the wave can be adjusted by the
projector makes realistic wave images. Because two 500W halogen speed controller.
light bulbs are mounted, the image is projected to a wide surface.

55
