Lamp Base R7s R7s R7s R7s R7s R7s R7s R7s
Cable Length 0.6m 0.9m 0.6m 0.9m 0.6m 0.9m 0.6m 0.9m
Plug C-20P C-20P C-20P C-20P C-20P C-20P C-20P C-20P
Adopt Pipe Diameter φ42.7mm φ42.7mm φ42.7mm φ42.7mm φ42.7mm φ42.7mm φ42.7mm φ42.7mm
Body Material Steel Steel Steel Steel Steel Steel Steel Steel
Color Black Black Black Black Black Black Black Black
Color Frame 272mm×236mm 272mm×236mm 272mm×236mm 272mm×236mm 272mm×236mm 272mm×236mm 272mm×236mm 272mm×236mm

QCL5A-300W / QCL5A-500W / QCL5A-750W※ / QCL5A-1000W※
Model QCL5A-300W QCL5A-500W QCL5A-750W※ QCL5A-1000W※
Voltage 100V 100V 100V 100V
Suitable Lamp J100V300WF JP100V500WBF JP100V750WBF JP100V1000WBF
JP100V500WCF JP100V750WCF JP100V1000WCF
Maximum Ambient Temperature 40° 40° 40° 40°
Maximum Surface Temperature 110° 160° 230° 115°
Body Weight 2.1kg 2.1kg 2.1kg 2.1kg
Minimum Safe Interval to Object 0.2m 0.4m 0.5m 0.6m
Minimum Throw Interval to Object 0.1m 0.1m 0.2m 0.2m
Reflector Aluminum Aluminum Aluminum Aluminum
Lamp Base R7s R7s R7s R7s
Cable Length 0.6m 0.6m 0.6m 0.6m
Plug C-20P C-20P C-20P C-20P
Body Material Steel Steel Steel Steel
Color Black Black Black Black
Color Frame 272mm×236mm 272mm×236mm 272mm×236mm 272mm×236mm

QCL5-200W8L / QCL5-300W8L / QCL5-500W8L
Model QCL5-200W8L-4C QCL5-300W8L-4C QCL5-500W8L-4C QCL5-500W8L-4CC6
Voltage 100V 100V 100V 100V
Total Wattage 1600W 2400W 4000W 4000W
Suitable Lamp J100V200WAF×8 J100V300WF×8 JP100V500WBF×8 JP100V500WBF×8
JP100V500WCF×8 JP100V500WCF×8
Circuit 4 4 4 4
Maximum Ambient Temperature 40° 40° 40° 40°
Maximum Surface Temperature 110° 130° 200° 200°
Body Weight 21.0kg 21.0kg 21.0kg 25.2kg
Minimum Safe Interval to Object 0.3m 0.3m 0.3m 0.3m
Minimum Throw Interval to Object 0.1m 0.2m 0.4m 0.4m
Reflector Aluminum Aluminum Aluminum Aluminum
Lamp Base R7s R7s R7s R7s
Cable Length 0.7m 0.7m 0.7m 0.7m
Plug C-30P C-30P C-30P C-60P
Connector C-30B C-30B C-30B C-60B
Body Material Steel Steel Steel Steel
Color Black Black Black Black
Color Frame 243mm×243mm 243mm×243mm 243mm×243mm 243mm×243mm

QCL5-200W9L / QCL5-300W9L / QCL5-500W9L
Model QCL5-200W9L-3C QCL5-300W9L-3C QCL5-500W9L-3C QCL5-500W9L-3CC6
Voltage 100V 100V 100V 100V
Total Wattage 1800W 2700W 4500W 4500W
Suitable Lamp J100V200WAF×9 J100V300WF×9 JP100V500WBF×9 JP100V500WBF×9
JP100V500WCF×9 JP100V500WCF×9
Circuit 3 3 3 3
Maximum Ambient Temperature 40° 40° 40° 40°
Maximum Surface Temperature 110° 130° 200° 200°
Body Weight 22.5kg 22.5kg 22.5kg 26.9kg
Minimum Safe Interval to Object 0.3m 0.3m 0.3m 0.3m

47
