LHQ-100W
Model LHQ-100W12L-3C LHQ-100W12L-3CD LHQ-100W12L-4C LHQ-100W12L-4CD
Voltage AC100V AC100V AC100V AC100V
Total Wattage 1200W MAX 1200W MAX 1200W MAX 1200W MAX
Suitable Lamp JD100V85W·NP/E×12 JD100V85W·NP/E×12 JD100V85W·NP/E×12 JD100V85W·NP/E×12
Circuit 3 3 4 4
Maximum Ambient Temperature 40° 40° 40° 40°
Maximum Surface Temperature 120°C 120°C 120°C 120°C
Body Weight 8.9kg 8.9kg 9.4kg 9.4kg
Minimum Safe Interval to Object 0.1m 0.1m 0.1m 0.1m
Minimum Throw Interval to Object 0.4m 0.4m 0.4m 0.4m
Reflector Aluminum Aluminum Aluminum Aluminum
Lamp Base E11 E11 E11 E11
Cable Length 0.35m 0.35m 0.35m 0.35m
Plug C-20P(Stage Left) C-20P(Stage Right) C-20P(Stage Left) C-20P(Stage Right)
Connector C-20B(Stage Right) C-20B(Stage Left) C-20B(Stage Right) C-20B(Stage Left)
Body Material Steel Steel Steel Steel
Color Black Black Black Black
Color Frame 146mm×112mm 146mm×112mm 146mm×112mm 146mm×112mm
LHQ-150W / LHQ-200W
Model LHQ-150W12L-3C LHQ-150W12L-3CD LHQ-150W12L-4C LHQ-150W12L-4CD LHQ-200W12L-3C LHQ-200W12L-3CD LHQ-200W12L-4C LHQ-200W12L-4CD
Voltage AC100V AC100V AC100V AC100V AC100V AC100V AC100V AC100V
Total Wattage 1800W MAX 1800W MAX 1800W MAX 1800W MAX 2400W MAX 2400W MAX 2400W MAX 2400W MAX
Suitable Lamp JD100V130W JD100V130W JD100V130W JD100V130W JCV100V200WGS×12 JCV100V200WGS×12 JCV100V200WGS×12 JCV100V200WGS×12
·NP/E×12 ·NP/E×12 ·NP/E×12 ·NP/E×12
Circuit 3 3 4 4 3 3 4 4
Maximum Ambient Temperature 40° 40° 40° 40° 40° 40° 40° 40°
Maximum Surface Temperature 130°C 130°C 130°C 130°C 140°C 140°C 140°C 140°C
Body Weight 11.7kg 11.7kg 12.2kg 12.2kg 11.7kg 11.7kg 12.2kg 12.2kg
Minimum Safe Interval to Object 0.1m 0.1m 0.1m 0.1m 0.1m 0.1m 0.1m 0.1m
Minimum Throw Interval to Object 0.5m 0.5m 0.5m 0.5m 0.6m 0.6m 0.6m 0.6m
Reflector Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum
Lamp Base E11 E11 E11 E11 E11 E11 E11 E11
Cable Length 0.35m 0.35m 0.35m 0.35m 0.35m 0.35m 0.35m 0.35m
Plug C-30P(Stage Left) C-30P(Stage Right) C-30P(Stage Left) C-30P(Stage Right) C-30P(Stage Left) C-30P(Stage Right) C-30P(Stage Left) C-30P(Stage Right)
Connector C-30B(Stage Right) C-30B(Stage Left) C-30B(Stage Right) C-30B(Stage Left) C-30B(Stage Right) C-30B(Stage Left) C-30B(Stage Right) C-30B(Stage Left)
Body Material Steel Steel Steel Steel Steel Steel Steel Steel
Color Black Black Black Black Black Black Black Black
Color Frame 146mm×146mm 146mm×146mm 146mm×146mm 146mm×146mm 146mm×146mm 146mm×146mm 146mm×146mm 146mm×146mm

BORDER & HORIZONT LIGHTS
PEQ/F/PE/FG/CH

The footlight series projects bright even light from the front of the stage.
Installed in a channel, or trough, below the front of the stage footlights have become standard equipment to illuminate
performers’ faces and costumes in the exacting productions of Japanese Kabuki and dance.

Model PEQ and PE - Model F for channel The FG - Embedded The CH - Hook
1 Reduced height footlights 2 installation 3 footlights for the 4 lights for the side
In situations where it is impossible In order to clear the runway stage
to construct a channel or trough audience’s view, these These footlights are When there is no channel
on-stage, or for temporary stages, footlights are installed in a designed to be installed on the stage or runway,
these reduced height footlights are channel below the stage. directly into the floor of the these footlights are the
mounted on the floor. Designed to When not in use, they can apron stage or runway. ideal choice. Equipped
be as low as possible, they do not be pivoted, using their Since the lights are level with with special fixtures, they
interfere with the audience’s view. attached fittings, into the the floor and covered with a can be hung directly on the
There are two models available: the channel for storage. strong heat resistant glass, facing of the stage. When
PEQ with a halogen bulbthe or the they can be used as part of not in use they can be
PE with an incandescent bulb. the stage itself. easily removed.

49
