01 MARUMO

1
MYF-1000A
This floodlight assures absolute safety by preventing flying glass splinters if the bulb happens to explode with the use of a
double-layered glass tube lamp, while also ensuring super-efficient brilliance and a lightweight lamp. Designing the lamp unit on the
outside of the equipment body reduces lamp overheating and improves ease of maintenance.
Voltage AC 100 V Minimum Safe Interval to Flammable Object 0.2m
Wattage 1000W Minimum Throw Distance from Flammable Object 0.5m
Suitable Lamp JPW100V750WB/G Lamp Base GX9.5
JPW100V1000WB/G Cable Length1.5m
Maximum Ambient Temperature 40°C Plug C-30P
Maximum Surface Temperature 195°C Body Material Aluminum
Body Weight 4.5kg Color Black
Tilt Angle/Suspended Use UP25° DN90° Color Frame 297mm×295mm
Tilt Angle/Stand Use UP90° DN30°

TBF-C-1500W / TBF-C-2000W / TBF-D-1500W / TBF-D-2000W
2
The TBF incorporates large rectangular reflectors. Its double ended halogen bulbs are oriented vertically to reduce shadows and
produce even lighting. There are two types, Type C with a clear Teflon filter to maintain safety without losing the effectiveness of its
brilliance, and Type D with a special diffusion filter for generating softer light. The filters can easily be exchanged as an option.

FLF-552-P / FLF-552-D
Model TBF-C-1500W TBF-C-2000W TBF-D-1500W TBF-D-2000W
Voltage AC100V AC100V AC100V AC100V
Wattage 1500W 2000W 1500W 2000W
Suitable Lamp JP100V750WBF×2 JP100V1000WBF×2 JP100V750WBF×2 JP100V1000WBF×2
JP100V750WCF×2 JP100V1000WCF×2 JP100V750WCF×2 JP100V1000WCF×2
Maximum Ambient Temperature 40°C 40°C 40°C 40°C
Maximum Surface Temperature 150°C 160°C 150°C 160°C
Body Weight 5.1kg 5.1kg 5.1kg 5.1kg
Tilt Angle/Suspended Use UP5°DN90° UP5°DN90° UP5°DN90° UP5°DN90°
Tilt Angle/Stand Use UP90°DN5° UP90°DN5° UP90°DN5° UP90°DN5°
Minimum Safe Interval to Flammable Object 0.3m 0.3m 0.3m 0.3m
Minimum Safe Interval to Flammable Object 0.7m 0.8m 0.6m 0.7m
Filter Clear Teflon Clear Teflon Diffusion Diffusion
Aluminum Aluminum Aluminum Aluminum
Reflector
Lamp Base R7s R7s R7s R7s
Cable Length 1.5m 1.5m 1.5m 1.5m
Plug C-30P C-30P C-30P C-30P
Body Material Aluminum Aluminum Aluminum Aluminum
Color Black Black Black Black
Color Frame 385mm×309mm 385mm×309mm 385mm×309mm 385mm×309mm

This lightweight, round floodlight produces a high quality light by using a high efficiency light source along with three effective
diffusion reflectors. There are two types, Type C with a clear Teflon filter to maintain safety without losing the effectiveness of its
brilliance, and Type D with a special diffusion filter for generating softer light. The filters can easily be exchanged as an option.

SLF-C-500W / SLF-D-500W
Model SLF-C-500W SLF-D-500W
Voltage AC100V
Wattage 500W 500W
Suitable Lamp JPD100V500WC/G JPD100V500WC/G
Maximum Ambient Temperature 40 ̊C
Maximum Surface Temperature 110 ̊C
Body Weight 3.8kg
Tilt Angle/Suspended Use UP10° DN90°
Tilt Angle/Stand Use UP90 ̊ DN10 ̊
MinimumSafeIntervaltoFlammableObject 0.1m
Minimum Throw Distance from Flammable Object 0.5m
