01 MARUMO

6 Nine MACRO Keys 7 Custom made system
Several procedures
We customize the layout and functions of MARIONET
can be programmed into STAR from its basic model, in order to fit any individual
one MACRO key and facility to be installed.
executed automatically.
Nine MACRO keys are
equipped as a standard so
that the operation becomes
more efficient.

MARIONET STAR
Type 据置型 Sub Master Fader 40×100ページ
Voltage AC100V±10% Sub Master チャンネルマスタ フリーマスタ エフェクト再生 シーン再生
Frequency 50/60Hz Part Fader 10
Wattage 600W Channel Group 1000
Operating Temperature Range 5°C~40°C Chase Memories 100パターン×100ステップ
Event Memories 30イベント Patch Page 5場面+持込卓用1場面/1イベント+客席
Memory Scene 1000シーン/1イベント External Memory リムーバブル メディア
Control Dimmer 2048ch Backup Function CPU デュアルシステム
Control Channel 2048ch Title Input Function キーボード
Lighting Control Signal DMX512(USITT1990) Monitor Display 17型LCD×2(最大:4台)
Preset Fader 60/80/100/120/140/160ch×3 JASCII 対応 可
(180/240/300/360/420/480ch×1) Wireless タブレットPC
Scene クロス/ムーブ(マルチキュー)タイム再生 舞台袖操作器 MF +サブマスター×10/20

MARIONET STAR
Type 移動型 Sub Master Fader 40×100ページ
Voltage AC100V±10% Sub Master チャンネルマスタ フリーマスタ エフェクト再生 シーン再生
Frequency 50/60Hz Part Fader 10
Wattage 600W Channel Group 1000
Operating Temperature Range 5°C~40°C Chase Memories 100パターン×100ステップ
Event Memories 30イベント Patch Page 5場面+持込卓用1場面/1イベント+客席
Memory Scene 1000シーン/1イベント External Memory リムーバブル メディア
Control Dimmer 2048ch Backup Function CPU デュアルシステム
Control Channel 2048ch Title Input Function キーボード
Lighting Control Signal DMX512(USITT1990) Monitor Display 17型LCD×2(最大:4台)
Preset Fader 40/60/80ch×3 ※ 組み合わせによ JASCII 対応 可
り160本まで可(120/180/240ch×1) Wireless タブレットPC
Scene クロス/ムーブ(マルチキュー)タイム再生 舞台袖操作器 MF +サブマスター×10/20
LIGHTING CONSOLE
PRETYNA-M

プリティナメガ
A lighting control console with a three-stage preset fader and memory functions. Manual operation using the preset fader
allows easy cueing and, in combination with the touch panel display, also allows writing of data and memory playback. This
the perfect lighting control console for creating flexible lighting as required for all-purpose halls and various types of
performance venues such as theaters or open spaces. A fixed dual CPU system or a portable single-system CPU are
available in line with the application and set-up conditions.

The fixed system has four types of fader Saving event data
1 arrays 2 You can save and manage event data
The fixed Pretyna-M has a lineup of four types of in batches, recording the lighting used for a
preset fader arrays: 60 in 3 tiers, 80 in 3 tiers, 100 in 3 single performance as patch data, scene
tiers or 120 in 3 tiers. These can also be used data, chaser data and sub-master data.
respectively as 180×1 tier, 240×1 tier, 300×1 tier and The memory can hold up data for up to
360×1 tier. The portable Pretyna-M has a lineup of 100 events, allowing reliable and efficient
three types of preset fader arrays: 40 in 3 tiers, 60 in 3 storage and management of often used
tiers, or 80 in 3 tiers. These can also be used lighting data or repeat program data.
respectively as 120×1 tier, 180×1 tier, and 240×1 tier.

62
