Dimming controller Switch box to Small sized dimming Connector for 15A house
1 attached directly on 2 switch on or off 3 controller for three 4 hold plug with ground
the yoke for one the light for three circuits CP series are expected to be
spotlight circuits CP-3DH2 is a midget controller used in ordinary facilities, not for
CP-1DH can be easily CP-1DH is a midget with three channel control professional stage facilities.
attached on the Yoke of a switch box for three faders. Luminaries up to 750W Therefore, outlets of these
spotlight or a boom pipe. circuits. Luminaries up to can be connected to be each control boxes are fitted to 15A
Brightness of the spotlight 750W can be connected circuit (1500W in total) and house plug with ground. Any
is controlled by the knob of to be circuit (1500W in brightness of the luminaries can equipment with C type plug
CP-1DH. CP-1DH is very total) and three groups of be controlled by operating three should NOT be used for this
convenient to adjust the light can be switched on faders. Effective use of these series. Please make sure that
brightness of light boom or off individually by each three faders helps you to create luminaries or cables have 15A
and portal spotlights switch. more ample lighting expression. house plug with ground.
individually.

CP-1DH
Voltage AC100V±10% Circuit Protector 15A(FCF2-15)
Frequency 50/60Hz Body Weight 1.5kg
Operating Temperature Range 5°C~35°C Color Black
Plug 15A House Connector with Ground. Accessories 漏電保護プラグ EX15C 1台
Cable Length 1.5m 本体固定バンド 2個
Connector 15A House Connector with Ground. 平型アーム取付板 1枚(本体に取付済み)
Channel 1 平型アーム取付ネジ 4本(本体に取付済み)
Maximum Loading Capacity 1200W 限流ヒューズ FCF2-15 1本
Minimum Loading Capacity 60W 接地アダプタ
Suitable Load Incandescent Lamp

CP-3DH2
Voltage AC100V±10% Maximum Loading Capacity 750W /ch 1500W in total
Frequency 50/60Hz Minimum Loading Capacity 60W
Operating Temperature Range 5°C~40°C Suitable Load Incandescent Lamp
Plug 15A House Connector with Ground. Circuit Protecto MCCB 2P10A×3 個
Cable Length 3.0m Body Weight 4.2kg
Power ELCB 2P15A 定格感度電流15mA Color Brown Gray
Connector 15A House Connector with Ground Accessories 接地アダプタ
Channel 3

CP-3SH
Voltage AC100V±10% Maximum Loading Capacity 750W /ch 1500W in total
Frequency 50/60Hz Minimum Loading Capacity —
Operating Temperature Range 5°C~40°C Suitable Load —
Plug 15A House Connector with Ground. Circuit Protecto 限流ヒューズ Fuse 10A(FCF2-10)
Cable Length 3.0m Body Weight 5.0kg
Power ELCB 2P15A 定格感度電流15mA Color Brown Gray
Connector 15A House Connector with Ground Accessories 限流ヒューズ Fuse FCF2-10 1本
Channel 3 接地アダプタ

⁕ TD2

CP-3SH
Voltage AC100V±10% Loading Capacity 2kW
Power Supply 1φ2w100V Minimum Loading Capacity 60W
Frequency 50/60Hz Suitable Load Incandescent Lamp
Operating Temperature Range 5°C~40°C Circuit Protecto MCCB20A 筒型ヒューズ20A
Receiving End M4ねじ Body Weight 2.0kg
Dimmer Output M4ねじ Color Blue
※ Load processing box is needed separately when the console is fixed to use.
