01 MARUMO

MOVING SYSTEM
ラクティア

A control console for remote controlled shooting systems in theaters and studios that has a compact
design with greatly improved operability. A mouse can be used to control everything from pan, tilt, focus
and color change to opening and closing of barndoors. The mouse can also be used with the numerical
keypad for even more rapid control. The patch screen allows easy change or correction of the load layout
using the mouse.
PanelLayout

ラクティア
Voltage AC100V±10% Stack Memories 200
Frequency 50 / 60Hz Chase Memories 99パターン×99ステップ
Wattage 20W Scene Setting Range 0.1~999.9
Operating Temperature Range 5~40°C Chase Setting Rang 1~99
Event Memories 50イベント Suitable Luminaires TRS、TRFシリーズ、RCCシリーズ
Memory Scene 1000シーン Control パン、チルト、フォーカス、カラー、バンドア
Control Channel 1024ch External Memory SDカード
Lighting Control Signal DMX512/1990 Monitor Display 17型LCD
Channel Group 200

LIGHTING CONSOLE
LIGHTING CONSOLE

MARUMO lines up the lighting control consoles broadly, not only for high-end users but also
for nonprofessional users.

Lighting control board
1 with Shooting Function
A lighting control board with
shooting functions in addition to
its lighting control functions.

2 MARIONET STAR
MARIONET STAR is a lighting control
PRETYNA-M
3 console, enables you to work with user-
PRETYNA-M is a
lighting control console friendly interface at the same time to
combining manual faders of accomplish exquisite lighting design.
three scene presets and
keyboard of electronic
memory system. DIMPACK
5 This lineup includes the Dim
Pack TZ, a portable lighting control
board with an all-in-one lighting,
and the Dim Pack CP Series,
4 PRELUCE 2 allowing optimum control of a
single or multiple lighting
PRELUCE 2 is a small lighting console with LED control function
and memory function. It is ideal for small halls, studios, banquet halls, instruments.
rehearsal halls, and gymnasiums.
