HS1-PB1 Power Box
Voltage 100V Output Protect Fuse 1A
Capacitance Range 12V5A Input Protect Fuse 5A
Cable Length 1.0m Body Material Steel
Plug C-20P Color Black
Connector NCS-253-AdF Body Weight 4.5kg
Output Cable Length 1.0m

MOVING SYSTEM
REMOTE CONTROL SYSTEM

MARUMO Remote Control Lighting System is a computerized Auto Focusing system with memory function.
MARUMO Remote Control System allows you to focus(pan & tilt) luminaires and save these position data of
each focusing. As lights can be reproduced in assigned positions by calling up a memory, set up work
becomes to be done in a short time. It corresponds to DMX512.

1
Theater
The very latest technology is being put to
use as stage lighting equipment for Kabuki-
za, where classical Japanese arts and Kabuki
are performed. One element of this is the
remote control system used. Kabuki-za has
three types of remote controlled spotlights:
suspension lights, balcony lights and ceiling
lights. Each has a unique light design, as for
example the lengths of the arms and shapes
differ for each installation location and
purpose. By introducing a remote controlled
system to precisely operate the spotlight pan,
tilt, focus adjustment and color change
functions, the amount of preparatory work is
both decreased and made more efficient.

2 Concert Hall
The JT Art Hall Affinis, well known as a concert hall providing
familiar music through various programs, including piano recitals
and chamber music, has remote controlled spotlights installed
on the light baton for the hall stage and above the audience
seats. The light control console with shooting functions handles
pan, tilt, and focus adjustment controls, shortening preparation
times and realizing safe and rapid lighting.
