01 MARUMO

LSF-605-CW Fresnel lens type
Voltage AC 100 V Minimum Throw Distance from Flammable Object 0.1m
Light control range 0%~100% Fuse F7161-125V-3A※2
Wattage 90 W Lens LES-5065-001 1500D 120F S
Control Channel 1ch Cable Length 1.0m
Color Temperature 5000 K※1 Plug C-20P
Color rendering typ. Ra80 Body MaterialAluminum
Maximum Ambient Temperature 35 °C Color Black / Ivory
Maximum Surface Temperature 105 °C Connector for DMX Input NC5MD-LX
Body Weight 6.8kg Connector for DMX Output NC5FD-LX
Tilt Angle UP 90°~DN 90° Connector for Power Input NAC3MPA
Tilt Angle/Suspended Use UP 50°~DN 90° Connector for Power Output NAC3MPB
Tilt Angle/Stand Use UP 90°~DN 50° Input Signal DMX512/1990※3
Minimum Safe Interval to Flammable Objec 0.1m Color Frame 195mm × 195mm(IRM-60A)

※ 1 LED elements have a degree of variation among
them; differences of light color and brilliance can occur
even for the same type.
※2 Spares are provided for parts built into the product.
※3 DMX512/1990 is the standard of USITT 1990. Stage light side Stage light rear Connector section

Ivory color model
[Custom made]

LSC-605-WW/LSC-605-CW Plano-convex lens type
Voltage AC 100 V Minimum Throw Distance from Flammable Object 0.1m
Light control range 0%~100% Fuse F7161-125V-3A※2
Wattage 90 W Lens LES-5065-001 1500D 120F S
Control Channel 1ch Cable Length 1.0m
Color Temperature 3000K / 5000k※1 Plug C-20P
Color rendering typ. Ra90 Body Material Aluminum
※ 1 LED elements have a degree of variation among Maximum Ambient Temperature 35 °C Color Black / Ivory
them; differences of light color and brilliance can Maximum Surface Temperature 105 °C Connector for DMX Input NC5MD-LX
occur even for the same type.
Body Weight 6.8kg Connector for DMX Output NC5FD-LX
※2 Spares are provided for parts built into the product.
Tilt Angle UP 90°~DN 90° Connector for Power Input NAC3MPA
※3 DMX512/1990 is the standard of USITT 1990. Tilt Angle/Suspended Use UP 50°~DN 90° Connector for Power Output NAC3MPB
Tilt Angle/Stand Use UP 90°~DN 50° Input Signal DMX512/1990※3
Minimum Safe Interval to Flammable Objec 0.1m Color Frame 195mm × 195mm(IRM-60A)

20
