04 DESISTI

LED Fresnel SPOTLIGHT
SOFT LED 4.7VW Vari-White

60W Vari-White from 2.800 to 6.600 °K - Enhanced CRI > 94
White light, with Adjustable Correlated Colour Temperature

OVERVIEW FEATURES
The De Sisti Vari-White LED Fresnel feature: ≫ 120 mm. (4.75”) diameter high quality, shock resistant
≫ CRI Greater than 94 at any CCT within the range Borosilicate glass Fresnel lens on spring supports.
≫ Variable White CCT technology, with a range from 2,800°K to 6,600°K ≫ High efficiency Self Stabilizing Active Cooling: Automatic,
≫ High output & Patented optics with the flexibility of variable colour thermal stabilization of the LED operating temperature is
temperature managed by an internal thermal sensor and CPU, variable
≫ 50,000 Hour LED ARRAY Life speed fan and heat sink to maintain the LED Array’s
≫ Universal A/C input voltage from 90-250V constant temperature at a maximum of 65°C. The hydro
≫ True smooth 100-0% Dimming via DMX 512 dynamic bearing fan operates silently with a very low RPM.
≫ Silent dimming with little to no colour shift ≫ Helix Screw driven focus mechanism which guides Teflon
≫ Universal power-Con AC input bushings supported LED ENGINE along 2 rods. This
The Super LED F4.7 Vary-White maintains the high efficiency DE SISTI ensures smooth operation during focusing, in any tilting
Internationally Patented optical system for LED FRESNEL, while the innovative position of the fixture. The Teflon bushings also provide a
variable white Phosphors LED ARRAY provides the ability to modulate the wiping action, which cleans the steel guide rails during focus
Correlated Colour Temperature from a minimum of 2.800°K to a Maximum of ≫ Available with either positive lock manual yokes for comfort
6.600°K with an enhanced CRI (Colour Rendering Index) higher than 94 at any and ease of handling, or pole operated yokes which can be
CCT within the range. used via the lighting pole for Panning and Tilting the lights as
The Lighting Fixture is DMX Controlled for: well as manually, since the mechanical activators are
≫ 0 to 100% with a super smooth Dimming equipped with clutches.
≫ STEP MODE for CCT Control: Increments of 400°K every 10% of DMX
variation
≫ CONTINOUS MODE for CCT control.
The fixture combines the classical SPOT/FLOOD beam control on an equivalent
FOCUS RANGE to a conventional lamp fresnel, with an excellent barn door
cutting.
It utilizes Standard accessories from the DE SISTI range of equivalent Fresnel
Lens size, such as Barndoor, Colour Frame, Cones, scrims.

POWER AND
DMX DAISY CHAIN
The SOFT LED permits both
POWER and DMX DAISY
CHAIN. In fact each Fixture is
respectively equipped with:

≫ 1 XLR5 pin Panel Mount Male & Female (DMX IN &
OUT) For Mains Supply
≫ 1 20A Powercon NAC3MPA BLUE (POWER IN)
≫ 1 20A Powercon NAC3MPB WHITE (POWER OUT)

Power to LED 60W DC Current to the LED (no flicker) Weight of Fixture M.O 3,5 kg. / P.O 5,4 kg.
PowerConsumption Europe 71W @ 230 V 50-60 Hz America 75W @ 120 V 50-60 Hz
This product uses a 5-pin XLR for DMX input and Weight of Barndoor 4 leaf 0,3 kg.. / 8 leaf 0,4 kg.
output. Weight of color frame Diameter 133 mm
DMX Data link Use a shielded data cables.
USITT DMX512-A Do not overload the daisy chain. Up to a maximum of Weight of color frame 0,13 kg.
32 devices can be used on a single DMX chain. Size of scrims & color frame Diameter 129 mm
Protection Type IP 22 Lens diameter 120 mm. 4.75”
LED BARS Lifetime50.000 hours with 70% Lumen Maintenance. DMX Channels Total 3 DMX Channels Base Dimmer/ Light Intensity
Max. Housing Surface Temperature 70° C Base +1 CCT Control Base +2 Mode of CCT Control (steps or continuous)
