P. 171

"SOFT LED 2" 230/240V 165W CRI>90 Daylight CCT, M.O. DMX LED Softlight including:
                                 ≫Mod. L4670.101 M.O. SOFTLED 4 - 230/240V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
                                 ≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS.  ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
                                 ≫165W LED engine  ≫Built In Power Supply 230-240V 50/60Hz DMX controlled.
                        LD4670.110  ≫Mod. DCL305140 Remote Phosphors Panel for SOFT LED 4, with CRI>90 DAYLIGHT Balanced Correlated Color Temperature (CCT)
                                 ≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
                                 ≫Mod. L4670.110.40 M.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
                                 DMX cable is not included, to be ordered separately
                                 "SOFT LED 2" 230/240V 165W CRI>95 Daylight CCT, P.O. DMX LED Softlight including:
                                 ≫Mod. L4670.101 M.O. SOFTLED 4 - 230/240V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
                                 ≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS.  ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
                                 ≫165W LED engine  ≫Built In Power Supply 230-240V 50/60Hz DMX controlled.
                        LD4671.110  ≫Mod. DCL305140 Remote Phosphors Panel for SOFT LED 4, with CRI>90 DAYLIGHT Balanced Correlated Color Temperature (CCT)
                                 ≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
                                 ≫Mod. L4671.110.40 P.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
                                 DMX cable is not included, to be ordered separately
                             DAYLIGHT BALANCED CCT (CRI higher than 90) 100/120V Versions
                                 "SOFT LED 2" 100/120V 165W CRI>90 Daylight CCT, M.O. DMX LED Softlight including:
                                 ≫Mod. L4670.201 M.O. SOFTLED 4 - 100/120V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
                                 ≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS.  ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
                                 ≫165W LED engine  ≫Built In Power Supply 100-120V 50/60Hz DMX controlled.
                        LD4670.210  ≫Mod. DCL305140 Remote Phosphors Panel for SOFT LED 4, with CRI>90 DAYLIGHT Balanced Correlated Color Temperature (CCT)
                                 ≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
                                 ≫Mod. L4670.110.40 M.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
                                 DMX cable is not included, to be ordered separately
                                 "SOFT LED 2" 100/120V 165W CRI>90 Daylight CCT, P.O. DMX LED Softlight including:
                                 ≫Mod. L4670.201 M.O. SOFTLED 4 - 100/120V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
                                 ≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS.  ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
                                 ≫165W LED engine  ≫Built In Power Supply 100-120V 50/60Hz DMX controlled.
                        LD4671.210  ≫Mod. DCL305140 Remote Phosphors Panel for SOFT LED 4, with CRI>90 DAYLIGHT Balanced Correlated Color Temperature (CCT)
                                 ≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
                                 ≫Mod. L4671.110.40 P.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
                                 DMX cable is not included, to be ordered separately
                     SOFT LED 2 OPTIONALS & ACCESSORIES
                         Mod                                           Description
                            HONEYCOMBS
                       L4675.200  BLACK Honeycomb for SOFT LED 4 fixtures, 1/4" black honeycomb, NARROW.
                       L4675.210  BLACK Honeycomb for SOFT LED 4 units, 1/2" black honeycomb, MEDIUM.
                       L4675.300  WHITE Honeycomb for SOFT LED 4 fixtures, 1/4" white honeycomb, NARROW.
                       L4675.310  WHITE Honeycomb for SOFT LED 4 units, 1/2" white honeycomb, MEDIUM.
                            INTENSIFIER
                       L4676.200  2 Leaf Intensifier for SOFT LED 4 fixtures
                            COLORFRAME
                       L4677.100  Colorframe for SOFT LED 4 fixtures
                            REMOTE PHOSPHORS PANELS
                       TCL305140  Remote Phosphors Panel for SOFT LED 4, with CRI>95 TUNGSTEN Balanced Correlated Color Temperature (CCT)
                       DCL305140  Remote Phosphors Panel for SOFT LED 4, with CRI>90 DAYLIGHT Balanced Correlated Color Temperature (CCT)
                            STANDARD YOKES MANUAL AND POLE OPERATED
                      L4670.110.40 Manual Operated Stirrup with B.S. spigot for SOFT LED 4 fixtures
                      L4670.220.40 Manual Operated stirrup (w/o spigot) for SOFT LED 4 fixtures
                      L4671.110.40 Pole Operated Stirrup with B.S. spigot for SOFT LED 4 fixtures
                      L4671.300.40 Pole Operated Stirrup with DIN spigot for SOFT LED 4 fixtures
                            DOUBLE YOKE MANUAL OPERATED FOR 2 PIECES OF SOFTLED 4
                                Manual Operated DOUBLE YOKE with B.S. spigot to assembly 2 pieces of SOFT LED 4 fixtures one on top of the other.
                      L4670.400.40  The Yoke allows the individual tilting of each SOFT LED 4 and a common tilting of both units.























                                                                    169
