SOFT LED 2 VERSIONS & MODEL NUMBERS
Mod Description
TUNGSTEN BALANCED CCT (CRI higher than 95) 230/240V Versions
"SOFT LED 2" 230/240V 100W CRI>95 Tungsten CCT, M.O. DMX LED Softlight including:
≫Mod. L4660.101 M.O. SOFTLED 2 - 230/240V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
≫100W LED engine ≫Built In Power Supply 230-240V 50/60Hz DMX controlled.
LT4660.110 ≫Mod. TCL305107 Remote Phosphors Panel for SOFT LED 2, with CRI>95 TUNGSTEN Balanced Correlated Color Temperature (CCT)
≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
≫Mod. L4660.110.40 M.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
DMX cable is not included, to be ordered separately
"SOFT LED 2" 230/240V 100W CRI>95 Tungsten CCT, P.O. DMX LED Softlight including:
≫Mod. L4660.101 M.O. SOFTLED 2 - 230/240V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
≫100W LED engine ≫Built In Power Supply 230-240V 50/60Hz DMX controlled.
LT4661.110 ≫Mod. TCL305107 Remote Phosphors Panel for SOFT LED 2, with CRI>95 TUNGSTEN Balanced Correlated Color Temperature (CCT)
≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
≫Mod. L4661.110.40 P.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
DMX cable is not included, to be ordered separately
TUNGSTEN BALANCED CCT (CRI higher than 95) 100/120V Versions
"SOFT LED 2" 100/120V 100W CRI>95 Tungsten CCT, M.O. DMX LED Softlight including:
≫Mod. L4660.201 M.O. SOFTLED 2 - 100/120V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
≫100W LED engine ≫Built In Power Supply 100-120V 50/60Hz DMX controlled.
LT4660.210 ≫Mod. TCL305107 Remote Phosphors Panel for SOFT LED 2, with CRI>95 TUNGSTEN Balanced Correlated Color Temperature (CCT)
≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
≫Mod. L4660.110.40 M.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
DMX cable is not included, to be ordered separately
"SOFT LED 2" 100/120V 100W CRI>95 Tungsten CCT, P.O. DMX LED Softlight including:
≫Mod. L4660.201 M.O. SOFTLED 2 - 100/120V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
≫100W LED engine ≫Built In Power Supply 100-120V 50/60Hz DMX controlled.
LT4661.210 ≫Mod. TCL305107 Remote Phosphors Panel for SOFT LED 2, with CRI>95 TUNGSTEN Balanced Correlated Color Temperature (CCT)
≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
≫Mod. L4661.110.40 P.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
DMX cable is not included, to be ordered separately

SOFT LED 2 VERSIONS & MODEL NUMBERS
Mod Description
DAYLIGHT BALANCED CCT (CRI higher than 90) 230/240V Versions
"SOFT LED 2" 230/240V 100W CRI>90 Daylight CCT, M.O. DMX LED Softlight including:
≫Mod. L4660.101 M.O. SOFTLED 2 - 230/240V FIXTURE HEAD, with - Soft Beam Alluminium Optycs
≫POWERCON IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
≫100W LED engine ≫Built In Power Supply 230-240V 50/60Hz DMX controlled.
LD4660.110 ≫Mod. DCL305107 Remote Phosphors Panel for SOFT LED 2, with CRI>90 DAYLIGHT Balanced Correlated Color Temperature (CCT)
≫Mod. 5403.135 3 mt. detachable Blue POWERCON power cable with bare ends
≫Mod. L4660.110.40 M.O. yoke with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
DMX cable is not included, to be ordered separately

165
