LED SOFTLIGHT
SOFT LED 4

165 W – Enhanced CRI
White light, Remote Phosphors either Tungsten (CRI>95)or
Daylight (CRI>91) balanced Correlated Colour Temperature

OVERVIEW
De Sisti Soft LED 4
This innovative Remote Phosphors 165W LED SOFTLIGHT, with its COLOR
RENDERING INDEX – CRI higher than 95 for the Tungsten CCT and Higher
than 91 for the Daylight CCT, provides a smooth and soft shadow projecting
beam, yet within a controlled field that makes it ideal for multiple camera set
ups. In fact, differently from typical LED PANELS with multiple LEDs, the DE
SISTI SOFT LED is a single Surface emitter with an optimized optics to
produces multidirectional light emission and reflection, yet within a field that
can be contained and controlled by means of the various honeycombs and
intensifiers made available.
Its main features are: FEATURES
≫ a controlled Beam and SOFT White Source, ideal for multiple camera use ≫Remote Phosphors Panel (interchangeable).
in the studio, with more effective control of the beam projection and ≫ Rugged and Lightweight Carbon Steel housing with low glare
effective Honeycombs black epoxy powder coating, with internal reinforces.
≫ producing SOFT SHADOWS, ≫High efficiency Automatic Cooling.
≫ with a beautiful EVEN DISTRIBUTION and a real quality projection with ≫ DMX (or local) control of the Light intensity from 0 to 100% with
precise reference white. smooth transition and theatrical quality dimming....flicker free at
≫ NO PIXEL EFFECT from the LED (which is a problem from many other any dimming level.
Brand’s LED PANELS in the market). ≫Special Optics for SOFT LIGHT and improved efficiency.
≫ Contained Size, reduced weight and exceptional efficiency for energy ≫ The accessories are secure regardless of the orientation of the
savings and lit Talent comfort. fixture. Accessories have been designed for one hand installation.
≫ Choice of Manual or Pole operation, the full dimming is through DMX and ≫ Available with either positive lock manual yokes for comfort and
the LEDs are supplied with DC throughout the 0 to 100% dimming range, ease of handling, or pole operated yokes which can be used via
for a full FLICKER FREE operation and super smooth cross fades. the lighting pole for Panning and Tilting the lights as well as
≫ The unit is self contained and requires no other external power supplies or manually, since the mechanical activators are equipped with
devices....both Mains and DMX connections are DAISY Chain able. clutches.

Power to LED 165W DC Current to the LED (no flicker) Protection Type IP 22
PowerConsumption Europe 190W @ 230 V 50-60 Hz America 205W @ 120 V 50-60 Hz
This product uses a 5-pin XLR for DMX input and LED BARS Lifetime 50.000 hours with 70% Lumen Maintenance.
output. Weight of Fixture with yoke M.O 8,3 kg. / P.O 9,6 kg.
DMX Data link Use a shielded data cables.
USITT DMX512-A Do not overload the daisy chain. Up to a maximum of Max. Housing Surface Temperature 70° C
32 devices can be used on a single DMX chain. DMX Channels 1 at 8bit: Dimmer 2 at 16bit: Dimmer

POWER AND DMX DAISY CHAIN
The SOFT LED permits both POWER and DMX DAISY CHAIN.
In fact each Fixture is respectively equipped with:
≫ 1 XLR5 pin Panel Mount Male & Female (DMX IN & OUT) For
Mains Supply
≫1 20A Powercon NAC3MPA BLUE (POWER IN)
≫1 20A Powercon NAC3MPB WHITE (POWER OUT)
