The Flat Fresnel
F8-200

INTELLIGENT LED LIGHTING

≫ Equivalent 400 watt HMI
Output
≫ High CRI, Quantum Dot
LED Fresnel
≫ Thin, Lightweight & Award
Winning Design Built for the Needs of Run and Gun
≫ Water Resistant IP54 Compact. Powerful. Convenient. It’s the new standard of portable LED lighting -
Rated The F8-200 allows you to punch through the mid-day sun with all the brightness
≫3200K or 5600K Versions and light quality you need. No need for an outlet, or an expensive cine-style battery.
The F8-200 allows you to use your existing standard camera batteries for bright,
≫Variable Spot Flood color accurate LED output. It’s everything you have been asking for in a Zylight -
≫ Single Shadow Beam The power of a 400 watt HMI, packed into just 4 inches deep, all while drawing only
Shaping 200 watts of power.
≫ Dual 14.4v Battery or
Worldwide AC Powering An Award Winning Platform Advances
Built upon the Award-winning F8 platform, the F8-200 continues the tradition of
combining high quality optics with a special blend of Quantum nanoparticles to
deliver a high quality of light matched only by traditional sunlight and incandescent
bulbs, while using a fraction of the energy. Plus, the F8-200 will perform in rain,
snow and sun with ease, thanks to it’s IP54 rating.

Packable Powerhouse!
In the eld, the F8-200’s sleek shape allows for multiple xutres to be packed into a
small case for lighter travel, or choose one of our custom single or dual ATA rated
soft cases, for easy shipping without the need to remove globes.

ZyLinkTM Wireless & DMX Control
Enjoy the exibility of Zylight’s advanced ZyLinkTM technology which rede nes the
term "lighting system." If one Zylight isn't enough, wirelessly link together as many
as you need to get the job done. Adjust the controls on any of the linked lights and
they all change, or dial in your set-up on different channels to individually control
your look remotely!

F8-200-D F8-200-T

F8-200 Fresnel Specifications
Mechanical
Lens Diameter 8” [200 mm]
Size 15” x 12.6” x 4.6” [380 x 320 x 120 mm]
Weight 10.25 lbs. [4.7 kg]
Mounting Standard Yoke Pole Yoke Mount (Optional)
Weather Resistance IP54
Electrical
Input 24-32 VDC, 4 -Pin XLR, (2) 14.4 V Battery Caddie (Optional)
Power 200W (10.0 Amps @ 24VDC)
Cooling Active
Output
Beam Angle Variable 16° - 70o
Dimming 0 –100%
Control Rear Panel Local, ZyLink Wireless, DMX512A.
Color Temperature F8-T (3200K), F8 - D (5600K)
LED Life 50,000 hrs. minimum.

175
