04 DESISTI

PHOTOMETRICS

PHOTOMETRIC DATA SUPER LED PHOTOMETRIC DATA SUPER LED
F10T HP, 230W-LED, 25808W Power F10T HP, 230W-LED, 25808W Power
Consumption, CRI 97 Consumption, CRI 95
C.C.T. (Correlated Color Temperature) balanced to C.C.T. (Correlated Color Temperature) balanced to
match 3.200°K TUNGSTEN LAMPS match 5.600°K DAYLIGHT LAMPS

SUPER LED F10 HP VERSIONS & MODEL NUMBERS
Mod Description
UNGSTEN BALANCED CCT (CRI higher than 90)
Super LED "F 10 T" HP - high power CRI>90 Tungsten CCT, M.O. LED Fresnel Spotlight including:
≫Mod. "F10THP".MO.H IP23 Rain Protected M.O. FIXTURE HEAD with - 250 mm. (10”) diameter Fresnel lens
The Model Number ≫PowerCON TRUE 1 IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
for the DIN Spigot ≫230W high power CRI>90 LED with Tungsten Balanced Correlated Color Temperature (CCT)
≫Built In UNIVERSAL Power Supply 80-270V 50/60Hz DMX controlled, PFC 0,96
Version is ≫ Mod. 5403.435 3 mt. det.ble Mains cable w/ PowerCON TRUE 1 mod. NAC3FX-W and other bare end - Mod. LT320.110.40 M.O. yoke
"F10THP".MO.DIN with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
≫Mod. 326.110 four leaf rotating barndoor ≫Mod. 327.100 colour frame
DMX cable is not included, to be ordered separately
Super LED "F 10 T" HP - high power CRI>90 Tungsten CCT, P.O. LED Fresnel Spotlight including:
≫Mod."F10THP".PO.H IP23 Rain Protected P.O. FIXTURE HEAD with - 250 mm. (10”) diameter Fresnel lens
The Model Number ≫POWERCON TRUE 1 IN & OUT PANEL MOUNTED CONNECTORS. - XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
for the DIN Spigot ≫230W high power CRI>90 LED with Tungsten Balanced Correlated Color Temperature (CCT)
≫Built In UNIVERSAL Power Supply 80-270V 50/60Hz DMX controlled, PFC 0,96
Version is ≫ Mod. 5403.435 3 mt. det.ble Mains cable w/ PowerCON TRUE 1 mod. NAC3FX-W and other bare end - Mod. 321.110.40 P.O. yoke
"F10T HP".PO.DIN with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
≫Mod. 326.110 four leaf rotating barndoor ≫Mod. 327.100 colour frame
DMX cable is not included, to be ordered separately
DAYLIGHT BALANCED CCT (CRI higher than 90)
