Super LED "F 10 D" HP - high power CRI>90 Daylight CCT, M.O. LED Fresnel Spotlight including:
≫Mod. "F10DHP".MO.H IP23 Rain Protected M.O. FIXTURE HEAD with - 250 mm. (10”) diameter Fresnel lens
The Model Number ≫PowerCON TRUE 1 IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
≫230W high power CRI>90 LED with Daylight Balanced Correlated Color Temperature (CCT)
for the DIN Spigot ≫Built In UNIVERSAL Power Supply 80-270V 50/60Hz DMX controlled, PFC 0,96
Version is ≫ Mod. 5403.435 3 mt. det.ble Mains cable w/ PowerCON TRUE 1 mod. NAC3FX-W and other bare end - Mod. LT320.110.40 M.O. yoke
"F10THP".MO.DIN with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
≫Mod. 326.110 four leaf rotating barndoor ≫Mod. 327.100 colour frame
DMX cable is not included, to be ordered separately
Super LED "F 10 D" HP - high power CRI>90 Daylight CCT, P.O. LED Fresnel Spotlight including:
≫Mod. "F10DHP".PO.H IP23 Rain Protected P.O. FIXTURE HEAD with - 250 mm. (10”) diameter Fresnel lens
The Model Number ≫PowerCON TRUE 1 IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
for the DIN Spigot ≫230W high power CRI>90 LED with Daylight Balanced Correlated Color Temperature (CCT)
≫Built In UNIVERSAL Power Supply 80-270V 50/60Hz DMX controlled, PFC 0,96
Version is ≫ Mod. 5403.435 3 mt. det.ble Mains cable w/ PowerCON TRUE 1 mod. NAC3FX-W and other bare end - Mod. 321.110.40 P.O. yoke
"F10DHP".PO.DIN with 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
≫Mod. 326.110 four leaf rotating barndoor ≫Mod. 327.100 colour frame
DMX cable is not included, to be ordered separately
DMX DAISY CHAIN CABLE 3 mt. (10') LONG, including:
5402.503 - 3 mt. (10') cable terminated with XLR 5 pin Connectors (male and female) at the ends, to allow daisy chain of DMX fixtures.
Super LED F10 OPTIONALS & ACCESSORIES
Mod Description
LT320.110.40 Steel tube Manual Operated stirrup with 28,57 mm. spigot (B.S. 1 1/8’’) with top end for attachment to “C”
LT 320.300.40 Steel tube Manual Operated stirrup with 28,00 mm. spigot (D.I.N.)
LT 320.220.40 Steel tube Manual Operated stirrup with M 12 Threaded hole
LT 321.110.40 Pole operated stirrup with 28,57 mm. spigot (B.S. 1 1/8"), with top end for attachment to "C" clamp.
321.300.40 Pole operated stirrup with 28,00 mm. spigot (D.I.N.)
325.310 Stainless Steel wire guard
326.110 Four leaf rotating barndoor
326.210 326.210
327.100 Colour Frame
328.100 Cone with two discs (with front aperture diameter: 190 mm. 150 mm. 110 mm.)
329.100 Set of scrims - Stainless steel
329.101 Full single scrim - Stainless steel
329.102 Full double scrim - Stainless steel
329.103 1/2 single scrim - Stainless steel
329.104 1/2 double scrim - Stainless steel
Aluminum black painted "C" clamp to hang fixtures overhead and for mounting on pipe with diameters up to 52 mm. (2"), with safety pin (no
91.210 adapters)
15.300 DIN Spigot 28 mm. to M12 thread stud washer and nut
95.100 28,57 mm. (1 1/8’’) spigot to M12 threaded stud with washer and nut for “C” clamp or stand mounting
20.100 Safety cable 800 mm. long 4 mm. diameter steel rope and safety catch
DGP-A1035 CS Combo steel stand 35
DGP-A9000N Wheel set with brakes

INCREASED OUTPUT
Super LED F10 HP versus Super LED F10:
The SUPER LED F10 HP is featuring a relevant
increase of Light output if compared to the
SUPER LED F 10.
The table shows the Main Lighting Parameters
comparison between the two products:
