04 DESISTI

321.110.40 Pole operated stirrup with 28,57 mm. spigot (B.S. 1 1/8"), with top end for attachment to "C" clamp.
321.300.40 Pole operated stirrup with 28,00 mm. spigot (D.I.N.)
325.300 Stainless Steel wire guard
326.100 Four leaf rotating barndoor (Large)
326.110 Four leaf rotating barndoor (Medium)
326.200 Eight way rotating barndoor (Large)
326.210 Eight way rotating barndoor (Medium)
327.100 Colour frame
327.200 Outrigger colour frame
327.210 Outrigger colour frame mounting kit
328.100 Cone with two discs (front aperture diam.: 190 mm. 150 mm. 110 mm.).
329.100 Set of scrims - Stainless steel
329.101 Full single scrim - Stainless steel
329.102 Full double scrim - Stainless steel
329.103 1/2 single scrim - Stainless steel
329.104 1/2 double scrim - Stainless steel
x 180° Bottom Light spill protection
91.200 Solid brass "C" clamp to hang fixtures overhead and for mounting on pipe with diameters up to 52 mm. (2"), with safety pin (no adapters)
20.100 Safety cable 800 mm. long with 4 mm. diameter steel rope and safety catch.
DGP-A110 Combo stand with lazy leg with 29 mm. Socket (1 1/8") and 16 mm. Spigot (5/8")
DGP-A9000 Caster set diam. 100 mm. braked

Quartz Halogen Fresnel Spotlight Mod. 300
MAGIS 300-500-600 W

Mod. 301

FEATURES
≫ Compact, highly efficient Fresnel lens spotlight using tungsten-quartz-
halogen filament lamps having GY 9,5 socket, L.C.L. of 46,5 mm. and
max. 650 kW power .
≫ 120 mm. diameter high quality, shock resistant Borosilicate glass Fresnel
lens on spring supports.
≫ Rugged and Lightweight STAINLESS STEEL housing with low glare
black epoxy powder coating, with internal double walls and reinforces.
≫ High efficiency convection cooling.
≫ GY 9,5 bi-post socket for tungsten halogen lamps.
≫ Special bimetallic clad aluminum reflector for high degree of reflectivity
and thermal resistance for long life.
≫ Brass Helix Screw on TEFLON socket driven focus mechanism which
guides Teflon bushings supported lamp carriage along 2 stainless steel
rails. This ensures smooth operation, and restricts bouncing or 4 brackets has a locking knob and is spring loaded, it can be locked to
chattering of the lamp carriage during focusing, in any tilting position of either safely hold barndoor, color frame and scrims or to be rotated 90°
the fixture, avoiding lamp failures during operation. The Teflon bushings and locked in an open position for fast accessories changes.
also provide a wiping action, which cleans the stainless steel guide rails ≫ The accessories are secure regardless of the orientation of the fixture.
during focus. The focusing mechanism can be activated from the rear of Accessories have been designed for one hand installation.
the fixture and the whole spot to flood action is accomplished with 1 ≫ Available with either positive lock manual yokes for comfort and ease of
and half turn of the focusing knob. handling, or pole operated yokes which can be used via the lighting pole
≫ The unit is equipped with a hinged lens door with wire-guard for easy for Panning and Tilting the lights as well as manually, since the
access to the lamp, it includes 4 accessory holding brackets. One of the mechanical activators are equipped with clutches.

134
