Specification
≫ Number of Contacts: 10, 16 ( contact us for more info. of other contacts) - Rated
Voltage: 400V-600V, according to UL, CSA
≫Die Electric: 3KV/ 1Min. ≫Volume Resistance: 1M/ 0hm
≫Temperature Range: -40~ +125 degree C
≫Protection Category: KM 06-KM48, IP65 when mated
≫Cross Section: 0.5-2.5mm2sq ≫Terminal Screws: steel M3 nickel plated
≫Protective Cover: KM06-KM24 Nylon 66. V-0; KM32-KM48 Aluminum
≫Die-Casting Alloy ≫Plug and Socket Insert: glass-fiber reinforced polycarbonate V-0
≫Contact Elements: copper alloy ≫Contact Surfaces: hard-silver plated
≫Earth Connector Part: brass nickel plated
≫Locking Levers: steel zinc plated ≫Pressing Lock-Nut: nylon 66. V-0
≫Gaskets: Neoprene (resistant to oil and aging)
≫Hood and Housing: aluminum die-casting alloy

KC 7-PIN Motor Cable Connector

Kupo PLS-4207 multiple connectors are often
applied to combine chain hoist power and control
cable as one. It makes a safe, compact and quick
setup rigging. Two rugged die cast aluminum alloy
half shells in black non-conductive nish for easy
cable assembly. Hard gold plated contacts in
soldering version and fully compatible with Socapax
SL37 family. The extended female ground contacts The reinforced locating tab on Casting shell inside with
allow making first / breaking last. insert disk and keyway offer a a body grounding boss
spinning resistance. guarantees full safety.

The standard line connectors come
with 3 different size compression strain reliefs.

277
