11 KUPO

20 Amp Panel Mount Stage Pin Connector

Features
≫ Both males and females with a screw-driven mounting clip provides
and easy mounting or removal from panels of various thickness.
≫Precision machined solid brass contacts.
≫ Stripped conductors could be inserted through the cross-hole for
pressure termination using wire shoes, which are included.
≫Ring terminations are also available for panel mount devices.
≫ Self-grounding mounting clip eliminates the need for a separate
ground wire.
≫Precisely t the industry standard panel cut-out.

DRAWINGS

Kupo Stage Pin Lamp Tester

Kupo Stage Pin lamp tester helps to diagnose Features
the bulb continuity before you rig the xture. ≫ Quickly test for lamp (bulb) continuity or
While LED indicator fails to response, please short by plugging into tester.
check the lamp (bulb) to make sure it is not ≫ Easily to indicate a good lamp while tester
burned out. If the bulb is good, then there is is buzzing and green LED lights up.
something wrong with wiring. It has a built-in ≫ Come with a key ring for clipping the
battery so external power is not required. Plus, tester to tool belt.
it comes with a buzzer and you will not only see ≫ Built-in CR2032 Lithium DC3V battery.
but hear authentically the test result.

Turn-lok, Nema Locking Connector
TURN-LOK connectors are the choice for quality electrical demand. UL and cUL listed, and also made to comply with NEMA
20A and 30A con guration. It is constructed of sturdy Nylon, PBT (thermoplastic) and premium grade of copper alloy,
ensuring the durability and reliability for power connection. Turn-Lok is available in both receptacles and plugs for voltage
AC125/250V, and covering up the needs for single and three phase applications.

Features Specification
≫ Ribbed main body for firm and secure gripping. ≫ Material: Nylon and PBT (thermoplastic) for line male and female; PBT
≫ Constructed of PBT (thermoplastic) and Nylon for greater impact- only for socket receptacle.
resistance and insulation. ≫ Terminals: 1.8mm Copper alloy for 30A line male/female, 1.6mm copper
≫Screw-type cord grip for maximum tightening force. alloy for 20A line male / female, 1.2mm copper alloy for receptacle.
≫ Terminal screw: #10 screws bronze.
≫ Wire accommodation: AWG #12 wire (for 20A connectors) / AWG #10
wire (for 30A connectors).

280
