11 KUPO

DRAWINGS

Optional Accessories

PLS-5219CPM Crimp Male Contact Ground disk to buss PLS- Strain Relief directly M2250 / 1-01 Crimp Tool.
PLS- Crimp Female Earth PLS- together the six ground 5219CBGD coupling into thread
housing (PG29).
contacts (solder
5219CPFE Contact 5219GDSK connectors only).
PLS-5219CPF Crimp Female Contact

Rubber dust cover with Rubber dust cover with Metal dust cover with Metal dust cover with
DC-M wire for line male DC-F wire for line female MC-M wire for line male MC-F wire for line female
connector. connector. connector. connector.

Cable Grip
Kupo cable grip is designed for PG29 thread 19-pin < PLS-CG18
connectors. It is for cable enclosure to prevent
pullout from tension, vibration, exure or motion.
Fabricated of stainless steel wire mesh weaves and
aluminum alloy ttings provide easy installation
bending control plus corrosion resistance. Grips with
knurled texture on the tting for excellent handling, Part Number Description
and neoprene bushing o ers watertight and PLS-CG18 Cable grip for 18C x 1.5 mmsq cable (or O.D. 18 mm cable).
dustproof protection. Support grip is weaved of dia. PLS-CG21 Cable grip for 18C x 2.5 mmsq cable (or O.D. 21 mm cable).
1.2 mm stainless steel wire for load capacity 60 kgs. PLS-SG21 Support Grip, feasible for O.D. 18-21 mm cable.

WPC 19-Pin Connector Series Features
≫ Mono-piece body is fabricated of rigid die-casted aluminum alloy, o
ering alternative choice for weather-oriented applications.
≫ Watertight (IP67) is achieved with a cable gland (FPG-42) a xed to
the cable entry point.
≫ Compatible with Kupo’s PLS and WPS series, as well as Socapex
419 and Veam VSC connectors.
≫ Hard gold-plated copper alloy machined contact, ensures the
excellent conductibility.
≫Non-conductive rst grade Bakelite provides great insulation.
≫ Extended ground contact at female side ensures “mate rst, break
last” for safety operation.
WPC-5219LF WPC-5219SM WPC-5219LM WPC-5219SF ≫Available in solder type only. ≫UL / cUL listed.
+ FPG-42 + FPG-42

274
