11 KUPO

K-LOK Dust Cover
Weatherproof snap back protective cover to t all compatible brands of 400A cam type receptacles.
Standard frame dimension allows retro t existing application easily. The gasket o ers a NEMA 3R
rated environmental seal that provides a protection against falling rain, dust or frost, and also
provides a safe way to cover exposed metal, while keeping the weather out when the receptacle is
not used. Kupo Dust Cover is made from a high impact resistant, ame retardant ABS material and
corrosion resistant stainless steel hardware. Five colors available for phase identi cation.

FOR 400A

FOR 150A

SINGLE POLE DISTRIBUTION BLOCK

400A Single Pole Distribution Block
Power distribution box for 400A single pole connector. Equipped with sturdy PA plastic box, this distro block is durable with
most portability. It comes with 1-Male 400A and 6-Female 400A panel mount connector. Dust cover is outfitted on all inlet
and outlet offering greatest protection. Available with 7 colors of 400A connectors.

400A SINGLE POLE DISTRIBUTION BLOCK
Power distribution box for
400A single pole connector.
Equipped with sturdy PA
plastic box, this distro block
is durable with most
portability. It comes with
1-Male 400A and 6-Female
400A panel mount
connector. Dust cover is
outfitted on all inlet and
outlet offering greatest
protection. Available with 7
colors of 400A connectors.
400A SINGLE POLE TAPPING T CONNECTOR

Inline adaptor in form of Male-Female-Female. Consist of Santoprene insulation sleeve and brass contact. Rated for max. 400Amp / 600Volts.
Compatible with major brands of cam type connectors. Available with blue, red, black, white and green.

270
