05 ZYLIGHT

Pro-Palette 350w Asymmetric Cyc Light
PART NUMBERS: MODEL
26-01077 Pro-Palette - 350w Asymmetric LED Cyc Light
MECHANICAL DATA
Extruded aluminum alloy and steel
Construction plates to form light weight and rigid fixture
construction
Paint / finish Epoxy-polyester powder paint
Steel stirrup with 12mm centre hole + DIN
Mounting & suspension mounting
Floor use Four plastic feet at fixture bottom
ELECTRICAL DATA
Power Input 100~240VAC single phase
Frequency/current 50/60Hz – 1.5A@220V
Power Consumption 350W at full power, 5W in sleep mode
Power Input PowerCon , Locking 3 pole connector, Blue
Power Output PowerCon , Locking 3 pole connector, White
Power Loss Last Scene Hold
Cable 2m, 3 x 1.5mm flexible cable
Standard Compliance EN60598-2-17, CE marked
OPERATIONAL DATA
Working Position 0° - 180°, suitable for truss mount and floor use
XLR 5-pin male/female connectors, USITT DMX-
Signal Input/output 512A
Control Modes RGBW / HSI / CCT / Effects
Dmx Channel 4(RGBW); 3(HSI); 2(effects mode); 2 (CCT mode)
Input Dmx Signal Loss Last scene hold
RDM ANSI E1.20-2006 RDM
Dimming Range 0 -100%, 1:4096
Led Temperature Built-in sensor real time monitoring
Cooling Dual cooling fan, automatic control
Led Lifetime ≥20.000 hr @25°C max.
OPTIC & EFFECT
Light source 128 high power CREE LEDs (RGBW)
Beam angle 54° horizontal, 80° vertical, fixed angle
Beam performance ratio 3.33:1
Distance to cyclorama 4.9' - 8.2' (1.5m ~ 2.5m)
RGBW; HSI (Hue, Saturation, Intensity); CCT
Color control modes (color temperature adjusting); Effect (Built-in
colour marcos)
Total Lumens 4630 (16' H x 13' W)
Beam Angle 73
PHYSICAL DATA
Weight 12.6 kg (28 lb.)
24" W x 12.1" H x 8.1" D (630mm W x 308mm H x
Size (mm ) w/o yoke 208mm D)
24" W x 16" H x 8.1" D (630mm W x 408mm H x
with yoke 208mm D)
Operation temperature 0-35°C (32-104°F)
Installation place Indoor
Noise level ≤35dB @1m
