04 DESISTI

LED Fresnel SPOTLIGHT CRI greater than 90
Super LED F14

Led Power 360W – Consumption 400W – PFC 0,96
White light, either Tungsten or Daylight balanced Correlated Colour Temperature
IP23 rated: “Rain Protected”

OVERVIEW FEATURES
The Super LED F14 is an HIGH OUTPUT LED ≫ 350 mm. (14”) diameter high quality, shock resistant Borosilicate glass Fresnel lens on
Fresnel lens spotlight by DE SISTI and includes: spring supports.
≫ the De Sisti Internationally Patented optical system for ≫ Rugged and Lightweight Carbon Steel housing with low glare black epoxy powder
LED FRESNELS and Plano Convex Optics. coating, with internal double walls and reinforces.
≫ It is available with either Tungsten (3.200°K) or ≫ High efficiency Self Stabilizing Active Cooling: Automatic, thermal stabilization of the
Daylight (5.600°K) Balanced CCT (Correlated Color LED operating temperature is managed by an internal thermal sensor and CPU,
Temperature), in both cases with a CRI higher than 95 variable speed fan and heat sink to maintain the LED Array’s constant temperature at a
and both in Manual or Pole operated versions. maximum of 65°C. The hydro dynamic bearing fan operates silently with a very low
≫It is using 360W High CRI - COB LED ARRAYs. RPM.
≫ The Fixture is rated for IP23 and it is ideal for Location ≫Special Patented Optics for LED Technology.
Work, it can be use under the RAIN and it has been ≫ Steel cable driven focus mechanism which guides Teflon bushings supported LED
tested for minus 20° C ambient temperature ENGINE along 2 rods. This ensures smooth operation during focusing, in any tilting
operation. position of the fixture. The Teflon bushings also provide a wiping action, which cleans
≫ It is DMX Controlled from 0 to 100% with a super the steel guide rails during focus. The focusing mechanism can be activated from both
smooth Dimming and a negligible variation of Colour front and rear of the fixture and the whole spot to flood action is accomplished with 1
Temperature while controlling the Light intensity. and half turn of the focusing knob.
≫ The lighting Performances of the Tungsten Balanced ≫ The unit is equipped with a hinged lens door with wire-guard, it includes accessory
CCT are similar from medium to full flood to those of a holding brackets. One of the 4 brackets has a locking knob and is spring loaded, it can
3kW tungsten Fresnels, while the Daylight Balanced be locked to either safely hold barndoor, color frame and scrims or to be rotated 90°
CCT is equivalent to a 1.200W. and locked in an open position for fast accessories changes. A double safety
The fixture combines the classical SPOT/FLOOD beam accessory bracket with spring loaded catch is available on request to be assembled
control on an equivalent FOCUS RANGE to a opposite to the locking knob.
conventional lamp fresnel, with an excellent barn door ≫ The accessories are secure regardless of the orientation of the fixture. Accessories
cutting. have been designed for one hand installation.
It utilizes Standard accessories from the DE SISTI range ≫ Available with either positive lock manual yokes for comfort and ease of handling, or
of equivalent Fresnel Lens size, such as Barndoor, pole operated yokes which can be used via the lighting pole for Panning and Tilting the
Colour Frame, Cones, scrims. lights as well as manually, since the mechanical activators are equipped with clutches.

Power to LED 360W Protection Type IP23(Rain Protection)
PowerConsumption Europe 400W @230V 50-60 Hz America 400W @ 120V 50-60Hz
LED ARRAY Lifetime 50,000 hours with 70% Lumen Maintenance. The Weight of color frame 0.5kg
LED ARRAYS are tested and certified up to LM80 Weight of Fixture M.O 20Kg
P.O 21.5Kg
DMX Channels 1 at 8bit Dimmer Weight of Barndoor 4leaf 1.85Kg
2 at 16bit Dimmer 8leaf 2.1Kg
Max. Housing Surface Temperature 70°C Lens diameter 350mm
Size of Barndoor ring Seat Diameter 402mm Size of scrims & Seat Diameter 395mm
Ring Diameter 399mm( ~ 15" ¾) color frame Accessory Diameter 393mm( ~ 15"½)
=
=
POWER AND DMX DAISY CHAIN
The Super LED FRESNELS permit both POWER and
DMX DAISY CHAIN. In fact each Fixture is respectively
equipped with:
For DMX:
≫ 1 XLR5 pin Panel Mount Male & Female (DMX IN &
OUT) For Mains Supply
≫1 20A Powercon NAC3MPA BLUE (POWER IN)
≫ 1 20A Powercon NAC3MPB WHITE (POWER OUT)
