a Maximum of 6.600°K with an enhanced CRI (Colour
Rendering Index) higher than 94 at any CCT within the
range.
The Lighting Fixture is DMX Controlled for:
≫0 to 100% with a super smooth Dimming
≫ STEP MODE for CCT Control: Increments of 400°K every
10% of DMX variation
≫CONTINOUS MODE for CCT control. POWER AND DMX DAISY CHAIN
The fixture combines the classical SPOT/FLOOD beam The Super LED FRESNELS permit both POWER and
control on an equivalent FOCUS RANGE to a conventional DMX DAISY CHAIN. In fact each Fixture is
respectively equipped with:
lamp fresnel, with an excellent barn door cutting.
It utilizes Standard accessories from the DE SISTI range of For DMX:
equivalent Fresnel Lens size, such as Barndoor, Colour ≫ 1 XLR5 pin Panel Mount Male & Female (DMX IN &
Frame, Cones, scrims. OUT) For Mains Supply
≫1 20A Powercon NAC3MPA BLUE (POWER IN)
≫ 1 20A Powercon NAC3MPB WHITE (POWER OUT)
FEATURES
≫ 250 mm. (10”) diameter high quality, shock resistant
Borosilicate glass Fresnel lens on spring supports.
≫ High efficiency Self Stabilizing Active Cooling: Automatic, PHOTOMETRICS
thermal stabilization of the LED operating temperature is
managed by an internal thermal sensor and CPU, variable PHOTOMETRIC DATA SUPER LED F6VW -
speed fan and heat sink to maintain the LED Array’s constant Vari White - 200W (CRI>94)
temperature at a maximum of 65°C. The hydro dynamic CCT tunable from 2.800 to 6.600 °K
bearing fan operates silently with a very low RPM.
≫ Steel cable driven focus mechanism which guides Teflon Illumination center values at Distances 1.415 lux 509 lux 127 lux
Central Light intensity (Candle Power) 12.735 cd
131 FC
12 FC
47 FC
bushings supported LED ENGINE along 2 rods. This ensures Illumination center values at Distances 1.747 lux 629 lux 157 lux
smooth operation during focusing, in any tilting position of the Central Light intensity (Candle Power) 15.723 cd 162 FC 58 FC 15 FC
fixture. The Teflon bushings also provide a wiping action, Light beam diameter with Beam Angle 2,80 mt 4,66 mt 9,33 mt
(50% of center value): 50,0°
30.6 ft
15.3 ft
9.2 ft
which cleans the steel guide rails during focus. The focusing
Light beam diameter with Field Angle 4,28 mt 7,13 mt 14,27 mt
mechanism can be activated from both front and rear of the (10% of center value): 71,0° 14.0 ft 23.4 ft 46.8 ft
fixture and the whole spot to flood action is accomplished 3 mt 5 mt 10 mt
with 1 and half turn of the focusing knob. FULL FLOOD DISTANCES 9.8 ft 16.4 ft 32.8 ft
≫ Available with either positive lock manual yokes for comfort
and ease of handling, or pole operated yokes which can be
used via the lighting pole for Panning and Tilting the lights as
well as manually, since the mechanical activators are
equipped with clutches. It is possible the conversion between
the two types.
3 mt 5 mt 10 mt
FULL FLOOD DISTANCES 9.8 ft 16.4 ft 32.8 ft
Illumination center values at Distances 15.950 lux 5.742 lux 1.436 lux
CentralLightintensity(CandlePower) 143.550 cd 1,482 FC 533 FC 133 FC
Illumination center values at Distances 19.800 lux 7.128 lux 1.782 lux
CentralLightintensity(CandlePower) 178.200 cd 1,839 FC 662 FC 166 FC
Light beam diameter with Beam Angle 0,42 mt 0,70 mt 1,40 mt
(50% of center value): 8,0° 1.4 ft 2.3 ft 4.6 ft
Light beam diameter with Field Angle 1,06 mt 1,76 mt 3,53 mt
(10% of center value): 20,0° 3.5 ft 5.8 ft 11.6 ft

Power to LED 200W Protection Type IP22
PowerConsumption Europe 220W @230V 50-60 Hz America 230W @ 120V 50-60Hz
DMX Channels Total 3 DMX CHannels Weight of color frame 0.28kg
Base Dimmer/Light Intensity Weight of Fixture M.O 13.5Kg / P.O 14.8Kg
Base+1 CCT Control Weight of Barndoor 4leaf 1.4Kg
Base+2 Mode of CCT Control 8leaf 1.65Kg
LED ARRAY Lifetime 50,000 hours with 70% Lumen Maintenance
Max. Housing Surface Temperature 70°C Lens diameter 250mm
Size of Barndoor ring Seat Diameter 314mm Size of scrims & Seat Diameter 306mm
Ring Diameter 313mm( ~ 12" ¼) color frame Ring Diameter 305mm(12")
=
