04 DESISTI

Super LED F10 VW Vari-White VERSIONS & MODEL NUMBERS
MOD DESCRIPTION
DAYLIGHT BALANCED CCT (CRI higher than 90)
Super LED "F 14 D" - high power CRI>90 Daylight CCT, M.O. LED Fresnel Spotlight including:
≫Mod. "F14D".MO.H IP23 Rain Protected M.O. FIXTURE HEAD with - 350 mm. (14”) diameter Fresnel lens
≫PowerCON TRUE 1 IN & OUT PANEL MOUNTED CONNECTORS. ≫XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
The Model Number ≫360W high power CRI>90 LED with Daylight Balanced Correlated Color Temperature (CCT)
for the DIN Spigot ≫Built In UNIVERSAL Power Supply 80-270V 50/60Hz DMX controlled, PFC 0,96
Version is ≫ Mod. 5403.435 3 mt. det.ble Mains cable w/ PowerCON TRUE 1 mod. NAC3FX-W and other bare end - Mod. LT350.110.40 M.O. yoke with
“F14D”.MO.DIN 28,57 mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
≫Mod. 356.110 four leaf rotating barndoor ≫Mod. 357.300 colour frame
DMX cable is not included, to be ordered separately
Super LED "F 10 D" - high power CRI>90 Daylight CCT, P.O. LED Fresnel Spotlight including:
≫Mod. "F14D".PO.H IP23 Rain Protected P.O. FIXTURE HEAD with - 350 mm. (14”) diameter Fresnel lens
≫PowerCON TRUE 1 IN & OUT PANEL MOUNTED CONNECTORS. - XLR 5 Pin DMX IN & OUT PANEL MOUNTED CONNECTORS.
The Model Number ≫360W high power CRI>90 LED with Daylight Balanced Correlated Color Temperature (CCT)
for the DIN Spigot ≫Built In UNIVERSAL Power Supply 80-270V 50/60Hz DMX controlled, PFC 0,96
Version is ≫ Mod. 5403.435 3 mt. det.ble Mains cable w/ PowerCON TRUE 1 mod. NAC3FX-W and other bare end - Mod. 351.110.40 P.O. yoke with 28,57
“F14D”.PO.DIN mm. spigot (B.S. 1 1/8"), with top end for "C" clamp
≫Mod. 356.110 four leaf rotating barndoor ≫Mod. 357.300 colour frame
DMX cable is not included, to be ordered separately
DMX DAISY CHAIN CABLE 3 mt. (10') LONG, including:
5402. 503 ≫3 mt. (10') cable terminated with XLR 5 pin Connectors (male and female) at the ends, to allow daisy chain of DMX fixtures.

Super LED F14
MOD Super LED "F 14" - OPTIONALS & ACCESSORIES
LT350.110.40 Steel tube (M.O.) stirrup with 28,57 mm. spigot (B.S.1 1/8") with top end for attachment to "C" clamp
LT350.300.40 Steel tube (M.O.) stirrup with 28,00 mm. spigot (D.I.N)
351. 110. 40 Pole operated stirrup with 28,57 mm. spigot (B.S. 1 1/8"), with top end for attachment to "C" clamp.
351. 300. 40 Pole operated stirrup with 28,00 mm. spigot (D.I.N.)
355. 310 Stainless Steel wire guard
356. 110 Four leaf rotating barndoor
356. 210 Eight way rotating barndoor
357. 300 Colour frame
358. 100 Cone with two discs (with front aperture diameter: 275 mm. 215 mm. 155 mm.).
359. 100 Set of scrims - Stainless steel
359. 101 Full single scrim - Stainless steel
359. 102 Full double scrim - Stainless steel
359. 103 1/2 single scrim - Stainless steel
359. 104 1/2 double scrim - Stainless steel
397. 100 Outrigger colour frame
397. 110 Outrigger colour frame holding kit
91.210 Aluminum black painted "C" clamp to hang fixtures overhead and for mounting on pipe with diameters up to 52 mm. (2"), with safety pin (no adapters)
15.300 DIN SPIGOT 28 mm. to M12 thread stud with washer and nut.
95.100 28,57 mm. (1-1/8") spigot to M12 threaded stud with washer and nut for "C" clamp or stand mounting
20.100 Safety cable 800 mm. long with 4 mm. diameter steel rope and safety catch.
DGP-A1035 CS Combo steel stand 35
DGP-A9000N Wheel set with brakes

INCREASED OUTPUT Super LED F14 versus
Super LED F10 HP:
The SUPER LED F14 is featuring a relevant increase of
Light output if compared to the SUPER LED F 10 HP.

The table shows the Main Lighting Parameters
comparison between the two products:

116
