LED Fresnel SPOTLIGHT
Super LED F6 VW Vari-White

120W Vari-White from 2.800 to 6.600 °K - Enhanced CRI > 94
White light, with Adjustable Correlated Colour Temperature

OVERVIEW
The De Sisti Vari-White LED Fresnel feature:
≫CRI Greater than 94 at any CCT within the range
≫Variable White CCT technology, with a range from 2,800°K to 6,600°K
≫High output & Patented optics with the flexibility of variable colour
temperature
≫50,000 Hour LED ARRAY Life FEATURES
≫Universal A/C input voltage from 90-250V ≫ 150 mm. (6”) diameter high quality, shock resistant Borosilicate
≫True smooth 100-0% Dimming via DMX 512 glass Fresnel lens on spring supports.
≫Silent dimming with little to no colour shift ≫ High efficiency Self Stabilizing Active Cooling: Automatic,
≫Universal power-Con AC input thermal stabilization of the LED operating temperature is
managed by an internal thermal sensor and CPU, variable
The Super LED F6 Vary-White maintains the high efficiency DE SISTI speed fan and heat sink to maintain the LED Array’s constant
Internationally Patented optical system for LED FRESNEL, while the temperature at a maximum of 65°C. The hydro dynamic
innovative variable white Phosphors LED ARRAY provides the ability to bearing fan operates silently with a very low RPM.
modulate the Correlated Colour Temperature from a minimum of 2.800°K to ≫ Steel cable driven focus mechanism which guides Teflon
a Maximum of 6.600°K with an enhanced CRI (Colour Rendering Index) bushings supported LED ENGINE along 2 rods. This ensures
higher than 94 at any CCT within the range. smooth operation during focusing, in any tilting position of the
The Lighting Fixture is DMX Controlled for: fixture. The Teflon bushings also provide a wiping action, which
≫0 to 100% with a super smooth Dimming cleans the steel guide rails during focus. The focusing
≫STEP MODE for CCT Control: Increments of 400°K every 10% of DMX mechanism can be activated from both front and rear of the
variation fixture and the whole spot to flood action is accomplished with
≫CONTINOUS MODE for CCT control. 1 and half turn of the focusing knob.
The fixture combines the classical SPOT/FLOOD beam control on an ≫ Available with either positive lock manual yokes for comfort and
equivalent FOCUS RANGE to a conventional lamp fresnel, with an excellent ease of handling, or pole operated yokes which can be used
barn door cutting. via the lighting pole for Panning and Tilting the lights as well as
It utilizes Standard accessories from the DE SISTI range of equivalent manually, since the mechanical activators are equipped with
Fresnel Lens size, such as Barndoor, Colour Frame, Cones, scrims. clutches. It is possible the conversion between the two types.

Power to LED 120W Protection Type IP22
PowerConsumption Europe 141W @230V 50-60 Hz America 150W @ 120V 50-60Hz
DMX Channels Total 3 DMX CHannels Weight of color frame 0.13kg
Base Dimmer/Light Intensity Weight of Fixture M.O 7.8Kg / P.O 9.1Kg
Base+1 CCT Control Weight of Barndoor 4leaf 0.63Kg
Base+2 Mode of CCT Control 8leaf 0.85Kg
LED ARRAY Lifetime 50,000 hours with 70% Lumen Maintenance
Max. Housing Surface Temperature 70°C Lens diameter 150mm
Size of Barndoor ring Seat Diameter 192mm Size of scrims & Seat Diameter 187mm
Ring Diameter 190mm(7" ½) color frame Accessory Diameter 185mm(7" ¼)
