11 KUPO

Adhesive Heat-Shrink Tube
With adhesive lined up inside, it is made for providing excellent electrical insulation and protection to cable joint and
termination. High impact, abrasion and corrosion resistance. UV and waterproof while sealed. Easily t over irregular
shape and large connectors.

Part Number KAMT-28 KAMT-55 KAMT-75 KABR-32075
Size (as supplied) /mm 28 55 75 60 (in) / 25 (out)
Size (as recovery) /mm 6 16 22 25 (in) / 8 (out)
Wall Thickness (as recovery) / mm 2.5 2.7 3.0 2.5
Standard Length 1.22 m 16 cm
Operatino Temperature (Degree) -55~100 -55~150
Min. Shrink Temperature (Degree) 80 110
Min. Fully Recovery 120 130
Temperature (Degree)
Water Absortion < 0.15% max. 1%
Shrinkage Ratio 3:1 2 : 1

KU-Hand

KU-HAND is designed for multi-task to protect users. Ergo-oriented brings comfort t to all users. Padded mesh on
leather top is for excellent ventilation; two-way stretch creates exibility. Synthetic leather palm is soft and durable.
Extra leather layer on palm, index nger and thumb for better strength and protection. Smooth texture of ngers and
reinforced ngertips make perfect on handling objects and reduce wear.
Part Number Size
KH-55MB Medium
KH-55LB Large
KH-55XLB Extra Large
KH-55XXLB Double Extra
