Multi-cable Extension Multi-cable Extension
Part Number Description Part Number Description
EXE18/1.5-5 18C x 1.5 mmsq multi-cable 5M, PLS-5219LM+PLS-5219LF TF18/1.5-1 18C x 1.5 mmsq multi-cable 1M, PLS-5219LM+2 PLS-5219LF
EXE18/1.5-10 18C x 1.5 mmsq multi-cable 10M, PLS-5219LM+PLS-5219LF TF18/1.5-2 18C x 1.5 mmsq multi-cable 2M, PLS-5219LM+ 2 PLS-5219LF
EXE18/1.5-20 18C x 1.5 mmsq multi-cable 20M, PLS-5219LM+PLS-5219LF TF18/2.5-1 18C x 2.5 mmsq multi-cable 1M, PLS-5219LM+2 PLS-5219LF
EXE18/1.5-30 18C x 1.5 mmsq multi-cable 30M, PLS-5219LM+PLS-5219LF TF18/2.5-2 18C x 2.5 mmsq multi-cable 2M, PLS-5219LM+2 PLS-5219LF
EXE18/2.5-5 18C x 2.5 mmsq multi-cable 5M, PLS-5219LM+PLS-5219LF TFF18/1.5-1 18C x 1.5 mmsq multi-cable 1M, PLS-5219LF+2 PLS-5219LM
EXE18/2.5-10 18C x 2.5 mmsq multi-cable 10M, PLS-5219LM+PLS-5219LF TFF18/1.5-2 18C x 1.5 mmsq multi-cable 2M, PLS-5219LF+2 PLS-5219LM
EXE18/2.5-20 18C x 2.5 mmsq multi-cable 20M, PLS-5219LM+PLS-5219LF TFF18/2.5-1 18C x 2.5 mmsq multi-cable 1M, PLS-5219LF+2 PLS-5219LM
EXE18/2.5-30 18C x 2.5 mmsq multi-cable 30M, PLS-5219LM+PLS-5219LF TFF18/2.5-2 18C x 2.5 mmsq multi-cable 2M, PLS-5219LF+2 PLS-5219LM

Motor Control Fly Cable
Part Number Description
MC-7/1.5-10M 7C x 1.5 mmsq multi-cable 10M, PLS-4207LM+PLS-4207LF
MC-7/1.5-20M 7C x 1.5 mmsq multi-cable 20M, PLS-4207LM+PLS-4207LF

Cable Assembly

Break-out or break-in cable set is assembled with superior H07RN-F cable.
Made of special cross-inked elastomer for excellent insulation. Great
suppleness o ering better resistance to inclement environmental condition to
oils and greases, as well as adverse chemicals and thermal e ects. In
accordance with RoHS and IEC/EN 60332-1-2 standard. Ideal for installation
on equipment in continual and interrupted operation under aggressive
condition such as construction site vehicles, generator, pumps and other
most extreme and severe usage industry applications.

≫Working Voltage: 450 / 750V ≫Working Temperature: -30°C / +60°C
(max. conductor temperature in service +85°C)

Head-to-ballst Cable
Part Number Description
1.5 mmsq 7M, WPS-2407LM-W+WPS-
HB-1.2K-7M 2407LF-W (ARRI 575W /1200W)
1.5 mmsq 15M, WPS-2407LM-W+WPS-
HB-1.2K-15M 2407LF-W (ARRI 575W/1200W)
KCWH 073 x 1.5 3C x 1.5 KCWH 073 x 2.5 3C x 2.5 mmsq 7M, WPS-2407LM-O+WPS-
mmsq Rubber Cable 2.5mmsq Rubber Cable HB-4K-7M 2407LF-O (ARRI 2500W/4000W)
2.5 mmsq 15M, WPS-2407LM-O+WPS-
Break-out / Break-in HB-4K-15M 2407LF-O (ARRI 2500W/4000W)
Part Number Description 3C x 16 mmsq+3C x 1.5 mm 7M, WPS-
BK3/1.5-1.2 3C x 1.5 mmsq rubber cable 1.2M, PLS-5219LM+6 TSP-20LF HB-6K-7M 2806LM+WPS-2806LF (ARRI 6000W)
BK3/1.5-1.2-CEE 3C x 1.5 mmsq rubber cable 1.2M, PLS-5219LM+6 CEE Female 3C x 16 mmsq+3C x 1.5 mm 15M, WPS-
3C x 1.5 mmsq rubber cable 1.2M, PLS-5219LM+6 SCHUKO HB-6K-15M 2806LM+WPS-2806LF (ARRI 6000W)
BK3/1.5-1.2-SCHUKO Female 4C x 16 mmsq+5C x 1.5 mm 7M, WPS-
BK3/2.5-1.2 3C x 2.5 mmsq rubber cable 1.2M, PLS-5219LM+6 TSP-20LF HB-12K-7M 2809LM+WPS-2809LF (ARRI 12KW)
BK3/2.5-1.2-CEE 3C x 2.5 mmsq rubber cable 1.2M, PLS-5219LM+6 CEE Female 4C x 16 mmsq+5C x 1.5 mm 15M, WPS-
HB-12K-15M 2809LM+WPS-2809LF (ARRI 12KW)
BK3/2.5-1.5 3C x 2.5 mmsq rubber cable 1.5M, PLS-5219LM+6 TSP-20LF
BI3/1.5-1.2 3C x 1.5 mmsq rubber cable 1.2M, PLS-5219LF+6 TSP-20LM HB-18K-7M 4C x 16 mmsq+5C x 1.5 mm 7M, WPS-
2809LM+WPS-2809LF (ARRI 18KW)
BI3/2.5-1.2 3C x 2.5 mmsq rubber cable 1.2M, PLS-5219LF+6 TSP-20LM 4C x 16 mmsq+5C x 1.5 mm 15M, WPS-
BI3/2.5-1.2-CEE 3C x 2.5 mmsq rubber cable 1.2M, PLS-5219LF+6 CEE Male HB-18K-15M 2809LM+WPS-2809LF (ARRI 18KW)
