11 KUPO
SAFETY WIRE
Kupo safety wire is fabricated of galvanized steel wire, and constructed in accordance with DIN3055 and DIN3060. It is used
as secondary bonding for rigging, lighting and other equipments to truss or stand, rendering a secondary exible coupling in
addition to regular xture.
SW-E01 / SW-E01B Ø 3.2mm, 7 x 19 wire
SWL(kg) A(cm) B(mm) C(mm) D(mm)
10 60 62 Ø5 13.5
This is safety wire comes with an aluminum tag on which
laser-engraved information indicates the year of
manufacturing, diameter of the wire, and safe working load.
Comply with European standard.
SW-01ST Ø 3.2mm, 7 x 19 wire
SWL(kg) A(cm) B(mm) C(mm) D(mm)
10 75 60 5.8 7.8
This safety wire is built with stainless steel hook and wire rope,
and terminated with aluminum ferrule. With its rusty-free
feature, it is an ideal choice for outdoor application.
SW-01 / SW-01B Ø 3.2 mm, 7 x 19 wire SW-02 Ø2.0mm,7x7wire,Ø3.0mm(withPVCjacket)
SWL(kg) A(cm) B(mm) C(mm) D(mm) SWL(kg) A(cm) B(mm) C(mm) D(mm)
10 75 60 5.8 7.8 5 70 50 4.8 7.0
