11 KUPO
ID RING
ID Ring is designed for dentification.
Six standard colors are available.
DMX Data Transmission Cable
Part Number Description
KCWDP222TBX Dataplex 1-pair, 22AWG
KCWDP224TBX Dataplex 2-pair, 22AWG
Audio Snake System
Kupo 16ch. audio snake system the stage box is designed for live applications where a single Mixer is used. It consists of
stage extension that allows separate IN & OUT channels on stage running only one cable on a long distance (stage to mixer).
Kupo 16CH. Audio Snake System is wired with individually-isolated channel shields.
JUNCTION BOX, KAB-1648MF
male and female XLR 3-pin
SNAKE TRUNK connector for each channel for FANTAIL, BK4816-1.5 RUGGED AUDIO 48PIN
high quality 16 ch multi-channel easy connection. All panel high quality microphone cable CONNECTOR
audio snake cable independent mount XLR 3-pin connector are with XLR-3 pin connector for ≫KAC-48LF line female
earth contact for each channel secured to the chassis with each channel; number collar ring ≫KAC-48LM line male
48 pin multi-pin connector. screws, not pop rivets. Dual 48 for quickly identification for 16 ≫KAC-48SM panel male
≫10M length (EXE48-10) pin connector (male and female) channels; Length: 1.5M. ≫KAC-48SF panel female
≫30M length ( EXE48-30) for easy system connection and
≫50M length (EXE48-50) signal distribution. The
construction of the box is made
from 1.4mm thickness steel,
black nish and equipped with
IN & OUT XLR 3-pin.
Multi-Cable Roller
Rolling a cable can be easy, but rolling couple of dozens can
be annoying. Multi-cable roller makes life easier. It is an easy-
to-use gear to organize the cable set. With several steps of
assembly, you can built it up and then roll di erent kinds of
cable e ectively. Take less e ort, do a nice job, all you need to
do is to run your cable set with this machine. Getting a great
cable management done can be that simple.
Item Description
Weight: 75 kgs
Dimension: 110(L) x 105(W) x 148(H) cm Cable drums sizes: 20
CR-234 / 30 / 40 cm Material: Cold rolled steel plate
Power Input: 110VAC/60Hz, 220VAC/50Hz Power
Consumption: 110V/6A, 220V/3A Roller Speed: 20 RPM
