Cable Crossover
The cable crossover is built to protect cables from moisture, oils, solvents,
and frame as a shield for impact resistance and load bearing. Kupo have
diverse cable crossovers which are made of high density press-molded latex,
backed with sturdy visible orange lid. Each has dog bone connector ends to
get connected to create any desired length. Easy to operate; protect the
cable through the doorway and eliminate the damage. Operation temperature
is -40 C° to 49 C° degree and the load bearing capacity is 2,000 kgs.

KCG-301-B [3 CABLE DUCTS]
Insulated YES Height 55 mm
Length 1000 mm Ducts Height 35 mm 15 kg
Width 310 mm Max. Load 2000 Kgs

KCG-301-B(BIG) [3 CABLE DUCTS] KCG-401-B [4 CABLE DUCTS]
Insulated YES Height 75 mm Insulated YES Height 55 mm
Length 900 mm Ducts Height 50 mm 23 kg Length 800 mm Ducts Height 40 mm 10.5 kg
Width 600 mm Max. Load 2000 Kgs Width 400 mm Max. Load 2000 Kgs

KCG-501-B(BIG) [5 CABLE DUCTS] KCG-501-B [5 CABLE DUCTS]
Insulated YES Height 75 mm Insulated YES Height 65 mm
Length 900 mm Ducts Height 50 mm 24 kg Length 770 mm Ducts Height 42 mm 18 kg
Width 600 mm Max. Load 2000 Kgs Width 485 mm Max. Load 2000 Kgs

EZ-TIE Applications
Ideal for sound, lighting and audio/video equipment. EZ-Tie is made by ≫ Help to organize cable set neatly with diverse colors.
Swiss-made looms and strictly quality control to assure consistent ≫Write-on identi cation label for great cable
quality with superior performance. Hook is made from A grade Nylon organization.
and has high peel and shear values with extended cycle life with ≫Sturdy Nylon buckle offers greater holding power
average 55 hooks per sq inch. It is forming with high temperature to against movement, and makes extension easily for
keep a better elasticity and durability. The Un-Napped loop brings a longer use.
very high cycle life with average 42 woofs per sq inch. EZ-TIE has been ≫Perfect for use as tie down for attaching equipment
tested under +93 degree C and -56.7 degree C for lasting 1000 hrs on the desk or table.
matting without failed. The working temperature from 80 degree C to ≫Convenient with wrapping up lighting stand legs to
-20 degree C. High cycle life with over 10,000 closures. Washable, UV keep them well fastened for transportation.
resistant to prevent discoloration. ≫Ideal for use as temporary hanger during installation.
