Dimensions (mm)
Item Amper Poles Key Voltage( V )
A/B C/D E F G H I
KHTN413 16 3 6h 230 62 47 25.8 52 85 43 4.5
KHTN414 16 4 6h 380 75 60 27 52 87 50 4.5
KHTN415 16 5 6h 380 75 60 27 52 91 56 4.5
KHTN423 32 3 6h 230 72 60 26.2 52 93 57.5 4.5
KHTN424 32 4 6h 380 75 60 30 52 87 58 4.5
KHTN4256 32 5 6h 380 72 60 30 63 100 64 4.5

Dimensions (mm)
Item Amper Poles Key Voltage( V )
A/B C/D E F H I
KHTN613 16 3 6h 230 75 60 16.5 45.5 64 4.5
KHTN623 32 3 6h 230 75 60 16.5 54.7 64 4.5
KHTN624 32 4 6h 380 75 60 16.5 55 64 4.5
KHTN625 32 5 6h 380 75 60 16.5 55 64 4.5

Schuko Connector

Schuko is one of industrial standard connector mostly used in Germany and part of Europe. It is widely adopted in
entertainment as well. Kupo supplies variation of assembly-type schuko for the need, including sti housing and rubber
encompassed model.

Technical Information
Contact Nickel-plated bronze; 2P+E. Shell PA66 with flame retarded Rubber (for rubber models only). Protection IP 44. Compliance CE

XLR Connector
